| CHIRP - Frequencies Supported | Full Mode (28-75 kHz), Narrow Mode (75-155 kHz), Wide Mode (130-250 kHz) |
| CHIRP - Imaging-Frequencies Supported | 455 kHz DI+ (435-535 kHz), 455 kHz SI+ (405-505 kHz), 800 kHz DI+ (800-860 kHz), 800 kHz SI+ (780-840 kHz), MEGA DI+ (1100-1200 kHz), MEGA SI+ (1050-1175 kHz) |
| Coast Master Compatibility, Custom Digital Readout, Custom View Selections, Heading Sensor GPS Compatibility, LakeMaster Compatibility, Navionics Gold/HotMaps Compatibility, Navionics Platinum + Compatibility, Platinum Compatibility, Temperature Alarm, Temperature Graph, Upgradable Software | Yes |
| Compatible With | AIS, AutoPilot, Minn Kota i-Pilot Link, Minn Kota Talon/Raptor, NMEA 2000, Radar, MEGA 360, One-Boat Network, Minn Kota Built-In MEGA DI, Minn Kota Built-In MEGA SI, Minn Kota US2 Sonar |
| Depth-Down Imaging | 125 ft (800 kHz), 250 ft (MEGA), 400 ft (455 kHz) |
| Depth-Sonar | 1,200 ft (standard transducer) |
| Display Colors Grayscale | 16-Bit |
| Display Pixel Matrix | 1280H x 800V |
| Display Size | 11" - 15" |
| Display Size - Diagonal | 12.1" |
| Interface | Touch Screen |
| Memory Card Slot | Dual SD |
| Mount-Standard | Gimbal |
| Mount-Standard Size | 13.82" W x 9.55" H x 4.79" D |
| Power Draw | 2.88 Amps |
| Power Input | 10.8-20 VDC |
| Power Output Peak-to-Peak | 8000 Watts |
| Power Output RMS | 1000 Watts |
| Range-Side Imaging (Side-To-Side) | 250 ft (800 kHz), 500 ft (MEGA), 800 ft (455 kHz) |
| Sonar-Coverage | 20?, 42?, 60?, (2) 86? & (2) 55? at -10dB |
| Sonar-Frequencies Supported | 50/83/200/455/800 kHz & 1.2 MHz |
| Sonar-Standard | Dual Spectrum CHIRP, MEGA Down Imaging+, MEGA Side Imaging+ |
| Temperature | Built In |
| Transducer, Transducer Mount Location | N/A |
| View Preset Keys, X-Press Menu System | No |
