INA HK3012

B00367GWG0

Needle BRG, Drawn Cup, Bore 30Mm, Od 37Mm

Needle BRG, Drawn Cup, Bore 30Mm, Od 37Mmzoom

Attributes

Key Value
Bearing DesignHK
Bearing Industry Number3012
Bore1.181 Inch | 30 Millime.
Bore Dia. (mm)30 mm
Bore Diameter30 mm
Cage MaterialSteel
Category - BDINeedle Non Thrust Rolle.
Closed EndNo
Compatible Ring Manufac.LR25X30X12,5
ComponentRoller Assembly with Ou.
Dynamic Load Capacity (.12,100 N
EAN4012802897364
EnclosureOpen
Full ComplementNo
Harmonized Tariff Code8482.99.65.30
Inch - MetricMetric
ItemNeedle Roller Bearing
Keyword StringBearing Needle
Long Description30MM Bore; 37MM Outside.
Lubricant MaterialGrease, Oil
Manufacturer Item NumberHK3012
Manufacturer NameSCHAEFFLER GROUP
Max. RPM8,400 RPM
Maximum Speed5,200 RPM Grease, 8,600.
Minimum Buy QuantityN/A
Minimum Temperature-30 Degrees C
NounRoller Assembly with Ou.
Number of RowsOne
Number of Rows of Rolle.Single Row
Other Features2 Rib Outer Ring | Draw.
Outside Dia. (mm)37 mm
Outside Diameter37 mm, 1.457 Inch | 37 .
Overall Width12 mm
Product Group - BDIB04144
RelubricatableNo
RetainerYes
Roller Material Grade100Cr7
Rolling ElementNeedle Roller Bearing
Seal MaterialNot Applicable
Self AligningNo
SeparableNo
Static Load Capacity (N)18,200 N
System of MeasurementMetric
Temp. Range (F)-5 Degrees to +212 Deg.
Thrust BearingNo
TypeDrawn Cup
UNSPSC31171512
Weight / Kilogram0.023
Weight / LBS0.051
Width0.472 Inch | 12 Millime.
Width (mm)12 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG30304568.85135Ina0.068.85 @ 1
thumbzoomBDI Express14123639.778460841In StockINA0.05069.77846084 @ 1
Grainger4ZZX510.451180INA10.45 @ 1
thumbzoomPurvisHK301211.341In StockINA11.34 @ 1
thumbzoomsustainablesupply.comC169040313.381In StockIna0.0513.38 @ 1
AmazonSCB00367GWG016.171In StockINA16.17 @ 1
