Jetzoom
brand:
manufacturer:

Attributes

Key Value
Bed Width8 in
Bed Width (In.)7-3/16
Distance Between Centers (In.)40
FeaturesSliding Headstock Pivots 360 Degrees with 7 Positive Locking Positions, Extended Spindle Nose Houses Dual Headstock Spindle Bearings, 4 in Cast Iron Risers Allow User to Adjust Height of Lathe for Maximum Comfort, Improved Tailstock Quill Locking Mechanism Incorporates an Anti-Rotation Key, Tailstock Features Acme Threads, Banjo Uses Non-Marring Positive Locking Wedge System to Securely Hold Tool Post, Spindle Lock Latch Frees Up Both Hands, Electronic Infinitely Variable Speed from 40 to 3200 RPM, 36 Integrated Indexing Positions, Newly Designed Headstock Locking Handle Accessible from Front of Lathe, Remote Emergency Stop Button Can Be Situated Along the Lathe Bed, Convenient Leg-Mounted Tool Holder, Rubber Tool Mat on Top of Headstock, E Drive Inverter Features a Built-In EMI Filter, Inverter is Enclosed for Added Protection
Frequency60 Hz
Horsepower2 hp
Hz60
IncludesFaceplate, Knockout Rod, Live Cone Center, Live Single Bearing Center, Spur Center, Tool Rest, Tool Rest Extension
ItemLathe
Motor HP2
Number of Spindle SpeedsVariable
Number of Threads (In.)0
Number of Threads (mm)0
Overall Height28 in
Overall Length73 in
Overall Width58 in
PhaseThree
Primary ApplicationWood Turning
Spindle Bore5/8 in
Spindle Bore (In.)5/8
Spindle Speed (RPM)40 to 3200
Spindle TaperMT-2
Swing Over Bed (In.)18-1/2
Voltage230/460V AC
