Attributes
| Key ^ | Value |
|---|---|
| Actuator Type | Plunger |
| Brand | Johnson Electric |
| Case Material | Case Material |
| Contact Configuration | SPST-CO |
| Contact Current Rating | 16 A |
| Contact Material | Contact Material |
| Depth | 13mm |
| Dimensions | 32 x 30 x 13mm |
| IP Rating | IP40 |
| Length | 32mm |
| Maximum Operating Temperature | +140?C |
| Mechanical Life | 10000000Cycles |
| Minimum Operating Temperature | -20?C |
| Operating Force | 3 N |
| Operating Temperature Range | -20 ? +140?C |
| Release Force | Release Force |
| Standards Met | CSA, ENEC, UL |
| Stock | Stock |
| Terminal Type | Terminal Type |
| Width | 30mm |
