Attributes
| Key ^ | Value |
|---|---|
| A | 15.75 |
| B | 12.17 |
| Body | Ductile Iron - Epoxy Coated |
| Bushing (3) | PTFE |
| C | 2.02 |
| D | 21.26 |
| Dead end service w/down stream flange (psi) | 200 |
| Dead end service w/o down stream flange (psi) | 100 |
| Disc | CF8M Stainless Steel |
| E | 16 : 1" |
| F | 15.34 |
| G | 3.41 |
| H | 5.51 |
| Inline service (psi) | 200 - 150 |
| J | 1.06 |
| K | 4 : 0.71 |
| L | 7.76 |
| Locating Pin (2) | Carbon Steel |
| Lower Shaft, Upper Shaft | 410 Stainless Steel |
| M | 3.00 |
| N | 1-8UNC |
| O-ring (2) | EPDM |
| Seat | Varies |
| Size | 16" |
| Temperature range (?F) | -30 to 250 |
| Weight | 211.64 |
