Attributes
| Key ^ | Value |
|---|---|
| Compatible with Product Type | Indexable Drills |
| Coolant Fed | Coolant Through |
| Coolant Feed | Through Center |
| Country of Origin (subject to change) | China |
| Features | Offset Allows the Drill Flange to be Clamped Against the Contact Face of the Tool Holder when the Threaded Pin is Tightened, Position of the Front Threaded Pin Opposite the Countersunk Point in Straight Shank Offset by 0.4mm per DIN 6595 |
| For Shank Type | DIN 6595 and ISO 9766 |
| For Use With | Cutting Tools |
| Includes | Clamping Screw |
| Item | Collet Chuck |
| Mounting Size | SK40 |
| Nominal Capacity | 32.00 mm |
| Nose Dia. | 52.00 mm |
| Overall Length | 172.00 mm |
| Overall Tool Side Dia. | 52mm |
| Programming Length | 75mm |
| Projection | 70.00 mm |
| Standards | DIN 69871 Form AD/B |
| Style, Type | SK 40 |
| Taper | 40 |
| Tool Side Dia. | 32mm |
