| Application | Application |
| Brand | KEMET |
| Coil Power | 150mW |
| Coil Resistance | 3.84 k? |
| Coil Voltage | 24V dc |
| Contact Configuration | Contact Configuration |
| Contact Material | Contact Material |
| Depth | Depth |
| Dimensions | 15 x 7.5 x 9mm |
| Electrical Life | Electrical Life |
| Features | Compact and Lightweight, Low Magnetic Interference, Low Power Consumption |
| Height | Height |
| Isolation Coil To Contact | 1.5kV ac |
| Length | 15mm |
| Maximum Operating Temperature | +85?C |
| Maximum Switching Power AC | Maximum Switching Power AC |
| Maximum Switching Power DC | 60 W |
| Maximum Switching Voltage AC | Maximum Switching Voltage AC |
| Maximum Switching Voltage DC | Maximum Switching Voltage DC |
| Minimum Operating Temperature | -40?C |
| Mounting Type | Surface Mount |
| Number of Poles | Number of Poles |
| Operating Temperature Range | -40 ? +85?C |
| Relay Switching Classification | Latching Relay |
| Standards Met | CSA, UL Recognized E73266 |
| Switching Current | Switching Current |
| Terminal Type | Terminal Type |
