Key ^ | Value |
---|---|
Bracket Mount | One attachment point for C-bracket Top and Bottom: 3/8"-16 |
Crossover Frequency | 1 kHz |
Depth | 16" (40.64cm) |
Directivity Factor (Q) | 6.3 |
Enclosure Material | 3/4" 7-ply birch plywood cabinet1" MDF motherboard |
Frequency Response | 60 Hz - 18 kHz (-10 dB @ 35 Hz) |
Height | 34.3" (87.12cm) |
Input Connection | Two-point barrier strip |
Nominal Impedance | 8 ohms, minimum 5.1 ohms at 112 Hz |
Overload Protection Klip | Overload Protection Circuit-HF |
Sensitivity | 101 dB |
Weight | 76 lbs. (34.54kg) |
Width | 19.8" (50.29cm) front 6.8" (17.27cm) rear |
