| Agency Compliance | FDA, ROHS, USDA, BSE/TSE |
| Bend Radius | 3 in |
| Color, Hose Color | Clear |
| Compatible Chemicals | Acetic Acid (Glacial), Acetic Acid 20%, Air, Beverage, Calcium Chloride, Carbon Dioxide, Chromic Acid 10%, Chromic Acid 5%, Citric Acid 50%, Dry Food, Fertilizers, Formic Acid, Fresh Water, Fungicides, Glycerin, Herbicides, Hydrochloric/Muriatic Acid (20%), Hydrofluoric Acid (20%), Hydrogen Peroxide, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Pesticides, Phosphoric Acid (40% Solution), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Sulfuric Acid (10% - 75%), Sulfuric Acid (to 10%), Wet Food |
| Country of Origin (subject to change) | Canada |
| Coupled Assembly / Bulk, Hose Configuration | Coupled Assembly |
| Coupling Material | Stainless Steel |
| Cover, Cover Material, Hose Cover Material, Hose Reinforcement Material, Hose Tube Material, Tube Material | PVC |
| Fitting Material | 316 Stainless Steel x 316 Stainless Steel |
| Fitting Size | 1-1/2 in x 1-1/2 in |
| Fitting Type | Cam and Groove C x Cam and Groove E |
| Fittings | Cam and Groove |
| For Media Type | Acetic Acid, Air, Beverage, Calcium Chloride, Carbon Dioxide, Chromic Acid, Citric Acid, Dry Food, Fertilizers, Formic Acid, Fungicides, Glycerin, Herbicides, Hydrochloric Acid, Hydrofluoric Acid, Hydrogen Peroxide, Nitric Acid, Pesticides, Phosphoric Acid (40% Solution), Sodium Bicarbonate, Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide, Sulfuric Acid, Water, Wet Food |
| Hose Fitting A Material, Hose Fitting B Material | 316 Stainless Steel |
| Hose Fitting A Size, Hose Fitting B Size, Hose Inside Dia. | 1 1/2 in |
| Hose Fitting A Type | Cam and Groove C |
| Hose Fitting B Type | Cam and Groove E |
| Hose Fittings | 316 Stainless Steel 1-1/2 in Cam and Groove C x 316 Stainless Steel 1-1/2 in Cam and Groove E |
| Hose Length | 20 ft |
| Hose Outside Dia. | 1 15/16 in |
| Inside Dia., Inside Dia. - Food Hose | 1-1/2" |
| Item | Food Hose |
| Length, Length - Food Hose | 20 ft. |
| Max. Pressure, Max. Pressure - Food Hose, Max. Working Pressure @ 70 F | 50 psi |
| Max. Vacuum, Max. Vacuum - Food Hose | 28" Hg |
| Meets | BSE/TSE, FDA CFR Title 21, ROHS and USDA |
| Not Recommended Chemicals | Acetic Acid 80%, Acetone, Ammonia (Liquids), Anhydrous Ammonia, Automatic Transmission Fluid, Brake Fluid, Chromic Acid 30%, Chromic Acid 50%, Diesel Fuel, Ethyl Acetate, Ethylene Glycol, Formaldehyde, Formaldehyde 40%, Fuel Oil, Gasoline, Heptane, Hexane, Hydraulic Fluid (Petroleum), Hydraulic Fluid (Synthetic), Kerosene, Methyl Chloride, Methyl Ethyl Ketone (MEK), Motor Oil, Naphtha, Turpentine, Vegetable Oil, Xylene |
| Outside Dia. | 1-15/16" |
| Reinforcement | PVC Helix |
| Safety Factor | 4:1 |
| Standards | BSE/TSE, FDA, ROHS, USDA |
| Temp. Range | -4 Degrees to 150 Degrees F |
| Vacuum Rating | 28.00 in Hg |
| Wet or Dry Application | Wet and Dry |
