| # of Conductor Pairs - AWG Size #1, Package Quantity | 1 |
| Bend Radius Installation Type | for stationary use |
| Cable Construction (Wire Gauge & Conductor Count) | 12 AWG/4C+(18 AWG/1Pr) |
| Cable Shielding Type/Material | Barrier tape; triple layer foil tape (100% coverage); tinned copper braid (85% coverage); foil shielded pairs |
| Conductor #1 - Wire Gauge (AWG) / Conductor Cross-Section (mm2) | 12 AWG (4 mm?) |
| Conductor Material | Finely stranded tinned copper |
| Conductor Pair #1 - Wire Gauge (AWG) / Conductor Cross-Section (mm2) | 18 AWG (1 mm?) |
| Conductor Stranding | Class 5 fine wire |
| Ethernet Category | 102 |
| Installation Type for Temperature Range | UL/CSA TC |
| Insulation Material | Lapp Surge Guard |
| Jacket Color | Black |
| Jacket Material | Thermoplastic polymer |
| Maximum Operating Temperature | +105?C |
| Minimum Bend Radius | 7.5 x cable diameter |
| Minimum Operating Temperature | -40?C |
| Nominal Voltage | 1000V |
| Operating Temperature Range | -25?C to +90?C |
| Shielding Cable | Shielding |
| Wire AWG #1 - # of Conductors | 4 |
