| Ambient Temperature, Max. Ambient Temp. | 40 Degrees C |
| Country of Origin (subject to change) | United States |
| Duty Cycle | Continuous |
| Footnotes | 24 |
| Frame | 56H |
| Full Load Amps, Full Load Amps @ 50Hz | 17.2/8.6 |
| HP, HP @ 50Hz | 1 1/2 |
| Hz | 50 |
| Ins. Class | F |
| Item | 50 Hz Motor |
| Length Less Shaft | 11 3/4 in |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor, No. of Speeds, Service Factor @ 50Hz | 1 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Manual |
| Nameplate RPM, RPM @ 50Hz | 1,425 |
| NEMA Design | None |
| Nominal Efficiency | 76 % |
| Overall Length | 13 1/2 in |
| Phase | Single |
| RPM Range | 1,401-1,500 |
| Shaft Dia. | 5/8 in |
| Shaft Length | 1 7/8 in |
| Standards | CE Certified, CSA Certified, UL Listed |
| Usable @ 200V, Usable @ 208V | No |
| Voltage Compatibility | 110/220-230V AC, 110/220V AC |
| Voltage, Voltage @ 50Hz | 110/220V AC |
| Weight | 52 lb |
