mpn:
brand:
manufacturer:
MPN:
Description:
HP: 1/12RPM: 14Volts: 110Amps: 1.3/0.65Hz: 50/60Phase: 1Frame: 42YEnclosure Type: TENV (Totally Enclosed Non Ventilated)Mounting: SpecialShaft Diameter: 0.750"Shaft Length: 1.625"Motor Shell Length: 5.50"Overall Length: 11.36"Rotation: ReversibleService Factor: 1.0Maximum Ambient Temperature: 40? CInsulation Class: FDu
Attributes
| Key | Value |
|---|---|
| Amps | 1.3/0.65 |
| Duty Cycle | Continuous |
| Enclosure Type | TENV (Totally Enclosed Non Ventilated) |
| Frame | 42Y |
| HP | 1/12 |
| Hz | 50/60 |
| Insulation Class | F |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 5.50" |
| Mounting | Special |
| Overall Length | 11.36" |
| Phase | 1 |
| Rotation | Reversible |
| RPM | 14 |
| Service Factor | 1.0 |
| Shaft Diameter | 0.750" |
| Shaft Length | 1.625" |
| Ship Weight | 24 lbs. |
| Volts | 110 |
