mpn:
brand:
manufacturer:
MPN:
Description:
Product Type: Three PhaseHP: 1/4RPM: 345Volts: 208-230/460Amps: 1.2/0.60Hz: 60Phase: 3Frame: 42YEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Mounting: SpecialShaft Diameter: 0.750"Shaft Length: 1.625"Motor Shell Length: 6.00"Overall Length: 13.07"Rotation: ReversibleService Factor: 1.0Maximum Ambient Temperature:
Attributes
| Key ^ | Value |
|---|---|
| Amps | 1.2/0.60 |
| Duty Cycle | Continuous |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Frame | 42Y |
| HP | 1/4 |
| Hz | 60 |
| Insulation Class | F |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 6.00" |
| Mounting | Special |
| Overall Length | 13.07" |
| Phase | 3 |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 345 |
| Service Factor | 1.0 |
| Shaft Diameter | 0.750" |
| Shaft Length | 1.625" |
| Ship Weight | 26 lbs. |
| Volts | 208-230/460 |
