mpn:
brand:
manufacturer:
MPN:
Description:
Product Type: DCHP: 1/4RPM: 125Volts: 180VDCAmps: 1Phase: DCFrame: 34Enclosure Type: TENV (Totally Enclosed Non Ventilated)Mounting: SpecialShaft Diameter: 0.750"Shaft Length: 1.625"Motor Shell Length: 6.06"Overall Length: 13.31"Rotation: ReversibleService Factor: 1.0Efficiency: 63.2%Maximum Ambient Temperature: 40? CI
Attributes
| Key ^ | Value |
|---|---|
| Amps | 1 |
| Duty Cycle | Continuous |
| Efficiency | 63.2% |
| Enclosure Type | TENV (Totally Enclosed Non Ventilated) |
| Frame | 34 |
| HP | 1/4 |
| Insulation Class | F |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 6.06" |
| Mounting | Special |
| Overall Length | 13.31" |
| Phase, Product Type | DC |
| Rotation | Reversible |
| RPM | 125 |
| Service Factor | 1.0 |
| Shaft Diameter | 0.750" |
| Shaft Length | 1.625" |
| Ship Weight | 17 lbs. |
| Volts | 180VDC |
