Attributes
| Key ^ | Value |
|---|---|
| Amperage Rating | 10.6/5.3 A |
| Amps, FL Amps | 10.6/5.3 |
| Application Type, Product Type | Brake Motors |
| Approvals | CSA, UL |
| Bearing Type | 16.07 |
| Bearing Type, Bearings, Drive End Bearing Type, Opp. Drive End Bearing Type | Ball |
| Category | Electric Motor |
| Class/Group, Model Number | C6K17FK21 |
| Composition | Steel |
| Construction, Enclosure Material, Frame Material, Material | Rolled Steel |
| Description: | 1HP..1725RPM.56.TEFC./V.1PH.60HZ.CONT.NOT.40C.1.0SF.RIGID C.BRAKEMOTORS.C6 |
| Dimensions | 16.73 in L |
| Drive End Bearing Size, Opp. Drive End Bearing Size | 6203 |
| Drive End Flange Type | C-Face |
| Duty Cycle | Continuous |
| Efficiency | 78.0% |
| Efficiency, FL Efficiency | 78 |
| Enclosure | TEFC |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Enclosure, Enclosure Type | Totally Enclosed Fan Cooled |
| Estimated Weight | 38.00 |
| Family Series | Leeson Motors, Brakemotors Series |
| Frame Remarks | FOOTED |
| Frame, NEMA Frame | 56C |
| Frequency Rating | 60 Hz |
| Frequency, Hertz, Hz | 60 |
| Gross Weight | 0 lbs |
| Horsepower | 1 hp |
| HP, Number of Speeds, Phase, Service Factor | 1 |
| Insulation Class | B, Class B |
| Item Condition | FACTORY NEW |
| Item Number, Manufacturer Part Number, MFG Part #:, Part Number | 111951.00 |
| KW | 0.75 |
| Manufacturer | Leeson Electric, Leeson |
| Manufacturer, Supplier: | LEESON ELECTRIC CORPORATION |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 6.50" |
| Mounting | Foot Mount, Rigid Base |
| mounting | C-face w/ rigid base |
| Mounting Type | C-Face/Rigid Base, C-Face Footed |
| Net Weight | 38 lbs |
| Nominal Voltage | 208 VAC, 240 VAC |
| Number of Poles | 4 |
| Overall Length | 16.73", 16.07 " |
| Phase | 3, 1 ph |
| Product Series | Brakemotors |
| Product Type | Capacitor Start/Capacitor Run |
| Rotation | Selective CCW, Reversible |
| RPM | 1,800 RPM, 1700 - 1800, 1800 |
| RPM, Speed (RPM) | 1725 |
| Service Factor | 1.0 |
| Shaft Diameter | 0.625", 0.625, UL;CSA |
| Shaft Length | 1.88", 1.88 |
| Shaft Size | 0.63 in Dia x 1.88 in L |
| Ship Weight | 40 lbs. |
| Special Features | Capacitor Start Motors, Washdown Duty Motors |
| UPC: | 691720010396 |
| Voltage | 110-120V, 208V, 230V |
| Voltage, Volts | 115/208-230 |
| Volts | 115/208/230 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | electricmotorwholesale.com | 111951 | 761.0 | 761.0 | 1 | In Stock | LEESON | 761.0 @ Qty: 1+ | ||
| AmazonTP | B0773QZSDH | 986.18 | 986.18 | 1 | In Stock | 5 | Leeson Electric | 986.18 @ Qty: 1+ | ||
 | MRO Supply | 2525607 | 1092.9 | 1092.9 | 1 | In Stock | Leeson | 1092.9 @ Qty: 1+ | ||
 | apexindustrialautomation.com | 111951.00 | 1172.77 | 1172.77 | 1 | 15 | Leeson | 1172.77 @ Qty: 1+ | ||
 | emotorpro.com | 111951.00 | 1232.41 | 1232.41 | 1 | In Stock | Leeson | 40.0 | 1232.41 @ Qty: 1+ | |
 | Global Industrial | WBB216654 | 1306.0 | 1306.0 | 1 | In Stock | 17 | Leeson | 1306.0 @ Qty: 1+ | |
 | Dealers Electric | 111951.00 | 1410.26 | 1410.26 | 1 | In Stock | Leeson | 40.0 | 1410.26 @ Qty: 1+ | |
 | Zoro | G2476388 | 1517.17 | 1517.17 | 1 | 1 | Leeson | 1517.17 @ Qty: 1+ | ||
| us.rs-online.com | 73397283 | 1519.85 | 1519.85 | 1 | In Stock | Leeson | 1519.85 @ Qty: 1+ | |||
 | motorsandcontrol.com | LE-111951.00 | 1549.06 | 1549.06 | 1 | 50 | Leeson Electric | 38.0 | 1549.06 @ Qty: 1+ | |
 | Galco | 111951.00-LEES | 1577.91 | 1577.91 | 1 | In Stock | Leeson | 38.0 | 1577.91 @ Qty: 1+ | |
 | cbtcompany.com | 111951.00 | 1716.08 | 1716.08 | 1 | In Stock | Leeson Electric | 1716.08 @ Qty: 1+ | ||
 | Walker Industrial | 111951-00 | 1755.6 | 1755.6 | 1 | In Stock | 10 | Leeson | 1755.6 @ Qty: 1+ | |
| kscdirect.com | LEE 111951.00 | 1902.18 | 1902.18 | 1 | In Stock | LEESON ELECTRIC CORPORATION | 1902.18 @ Qty: 1+ | |||
 | pumpproducts.com | 111951.00 | 2004.37 | 2004.37 | 1 | In Stock | Leeson | 2004.37 @ Qty: 1+ | ||
 | Raptor Supplies | AJ2QGP | 2310.2663805 | 2310.2663805 | 1 | In Stock | LEESON | 2310.2663805 @ Qty: 1+ |
