mpn:
brand:
manufacturer:
MPN:
Weight:
1.0
Weight:
1.0 LB
Preferred Price:
39.22
Price:
39.22
Min Simple Price:
6.24
Absolute Min Price:
31.58
Min Price:
31.58
Dimensions:
[450.0, 200.0, 140.0]
qty:
1
simpleSku:
TE0Mzk:::TR5251W
sku:
TE0Mzk::M1:TR5251W@x3
condition:
11
seller:
us.rs-online.com
amzMan:
legrand
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| amperage rating, Size | Retail |
| Amps - Plugs and Receptacles, Current Rating | 15 A |
| Application, Application Environment | Commercial |
| average life, element, Finish, insulation, Number of Ports, Sensor Type, Wire Size | 70lbs Fan Max Weight, 150lb Fixture Max Wgt |
| Brand | Pass and Seymour, Legrand |
| Cable Entry | For Connecting Ground Conductor In Conduit To Water Pipe |
| Carton | 1 |
| Category Description, Classification | Residential Receptacles |
| class, Contact Configuration, Lens Color, load, Poles | Open Office, Retail |
| Coil Voltage | 60.000 60.000 |
| Color, Color - Plugs and Receptacles | White |
| Compatible Wire Size | #14 to #10 AWG |
| connection | Back and side wire |
| Connection Type | Back and Side Wired |
| Construction | Lighting |
| Cord Type, Knockouts | High-pressure washdowns. Particle build-up. Condensation. Corrosive substances. Food and beverage processing plants can be harsh, challenging environments. Fortunately, we have a full menu of electrical devices that keep things running smoothly while protecting people and equipment. IEC PIN & SLEEVE DEVICES Watertight Plugs & Connectors ? Thermoplastic elastomer body resists water, oils, lubricants and soaps while maintaining NEMA 4, 4X, 6, 6P, and IP65, 66, 67 ratings ? Ideal for washdown areas rated wa |
| Current Stock | 57 |
| cutout, included, material composition | Illumination - ability to locate device in the dark |
| Description | Recep SGL Tamper Resis 15A/125V WH |
| Dielectric Strength | Withstands 2000V minimum |
| environmental conditions | Flammability: UL94 V2 |
| extra long description | P&S TR5251W RECEP SGL TAMPER RESIS |
| Face Diameter | 1.38 in |
| Face Plate Height | 1.96 in |
| Face Plate Width, Length | 1.296 in |
| Features | Tamper-Resistant Construction Spec Grade Single Receptacle Back & Side Wire 15amp 125volt White |
| GTIN | 00785007241938 |
| Height | 3.28 in |
| International Shipping, Power Indicator, Surge Suppression, Weather Resistant - Plugs and Receptacles | No |
| interrupt rating | 7.000 7.000 |
| Item, Item - Plugs and Receptacles | Receptacle |
| Lamp Type | Light Commercial, Residential, Restroom |
| Long Description | Single Receptacle, 15 A, 125 V, 2 Poles, 3 Wires, #14 to #10 AWG Compatible Wire Size, Back and Side Wired Connection, Wall Mount, 1.296 in Length, 1.190 in Width, 3.28 in Height, Nylon Material, White, Heavy Duty Corrosion Resistant, 0.1800 lb |
| Manufacturers Part Number, Mpn | TR5251W |
| Material | Nylon |
| Maximum Wire Size | 10 AWG |
| Minimum Wire Size | 14 AWG |
| Mount Hole Center-to-Center Height | 3.68 in |
| Mounting | WALL |
| Mounting Type | Wall Mount |
| Mounting Type - Plugs and Receptacles | Flush |
| nema rating, NEMA Receptacle Configuration - Plugs and Receptacles | 5-15R |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Outlet Type - Plugs and Receptacles, Receptacle Type | Single |
| Package | 100 |
| package quantity | 10 CT;100 PK |
| Primary Type | Straight Blade |
| Product Type, Type | Single Receptacle |
| Resistance Properties | Heavy Duty Corrosion Resistant |
| sensing range | Cooper IRiS |
| Series | TradeMaster Series |
| Short Description | 15 A, 125 V, Single Receptacle, White |
| SKU | ZO-G7766477 |
| Special Features | Dual Mechanical Shutter System to Help Prevent Insertion Of Foreign Objects. Two Drive Screws Anchor Strap to Back Body and Face Where Abrupt Removal Torque Is Greatest.Zinc-Plated Steel Strap for Added Strength. Backed-Out |
| standard | UL498, CSA C22.2 No. 42 |
| Standards Met | UL 498;CSA c22.2 no. 42;UL 94 v2;RoHS Compliant;Federal Specifications |
| Style | Fluorescent industrial lighting fixture |
| sub brand | Pass & Seymour |
| SubCategory | Electrical |
| Tamper Resistant | Yes |
| Temperature Rating | Temperature Rise: Maximum 30?C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60?C, minimum -40?C without impact |
| terminals | Single Sided |
| Termination | Screw |
| Type | Tamper-Resistant Construction Spec Grade Single Receptacle |
| UNSPSC | 39121406 - Electrical receptacles |
| UPC | 785007241938 |
| UPC Code | 78500724193 |
| Voltage - Plugs and Receptacles | 125V AC |
| Voltage Rating | 125 V, 125 |
| Wattage | Electrical power is expressed in Amps and Volts. |
| Weight | 0.1800 lb |
| Weight per each | 0.178 |
| Width | 1.190 in |
| Wire Size | #14 - #10 |
| Wiring Method - Plugs and Receptacles | Back and Side |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| us.rs-online.com | 70050891 | 6.24 | 6.24 | 1 | 6 | Pass & Seymour | 6.24 @ Qty: 1+ | |||
 | Zoro | G7766477 | 6.39 | 6.39 | 1 | 638 | Legrand | 16.0 | 6.39 @ Qty: 1+ | |
| AmazonTP | B008SEOLXW | 6.58 | 6.58 | 1 | In Stock | 1 | Legrand-Pass & Seymour | 6.58 @ Qty: 1+ | ||
 | Elliott Electric | TR5251W | 7.5171 | 7.5171 | 1 | In Stock | Legrand-Pass & Seymour | 0.178 | 7.5171 @ Qty: 1+ | |
| Grainger | 53CX74 | 7.75 | 7.75 | 1 | 764 | 0 | LEGRAND | 7.75 @ Qty: 1+ | ||
 | sustainablesupply.com | C2894732 | 8.69 | 8.69 | 1 | In Stock | Legrand | 0.18 | 8.69 @ Qty: 1+ | |
| Amazon | B008SEOLXW | 9.49 | 9.49 | 1 | In Stock | 85 | Legrand-Pass & Seymour | 9.49 @ Qty: 1+ | ||
 | simsupply.com | ZO-G7766477 | 13.54 | 13.54 | 1 | 57 | Legrand | 13.54 @ Qty: 1+ | ||
 | Raptor Supplies | CD3FQH | 27.8331885 | 27.8331885 | 1 | In Stock | LEGRAND | 27.8331885 @ Qty: 1+ |
