| Color - Motion Sensing and Dimming | White |
| Communication Method - Motion Sensing and Dimming | Hard Wired |
| Country of Origin (subject to change) | China |
| Coverage Angle - Motion Sensor | 360 Degrees |
| Coverage at Suggested Mounting Height | 1,000 sq ft |
| Description/Special Features | High Inrush Stability, Industry-Exclusive "Fail-Safe" Circuitry, Industry-Exclusive Self-Configuring Local Manual Switch Input, Manual Switch and Emergency Override are Class 1 or Class 2 Circuits. Class 2 Circuits Provided for Flexibility, Output Short Circuit Protection, Presentation Mode Allows User to Turn Lights Off and Keep Them Off While the Room is Occupied, Vacancy Sensing Time Outs |
| Includes | (2) #6-32 Screw, 360 Degrees Perforated Mask, Angled Light Pipe, Emergency Label, Half Mask, Low Voltage Connector, Mid-Range Lens, Mounting Plate, Tubing Barrier |
| Installation Location - Motion Sensor | Ceiling |
| Item | Occupancy Sensor |
| Item - Motion Sensing and Dimming | Occupancy Sensor with Photocell |
| Lighting Technology | Tungsten |
| Max. Capacity @ 120VAC | 800V (Ballast), 800W ( Tungsten), 8A (Electronic Ballast) |
| Max. Capacity @ 277VAC | 6A/6AX (Electronic Ballast, Magnetic Ballast, 1/3 HP Motor) |
| Operating Voltage - Motion Sensing and Dimming | 120/230/277 V AC |
| Sensing Technology | Passive Infrared, Photocell, Ultrasonic |
| Standards | ASHRAE 90.1, CE Compliant, cUL Listed, NOM Certified, NY LLC48 Compliant, RoHS Compliant, Title 24, Part 6, UL 773A, UL 924 |
| Suggested Mounting Height - Motion Sensor | 8 ft to 12 ft |
| Time Delay - Motion Sensor | 30 sec to 30 min |
| Time Delay Adjustment Method - Motion Sensor | Adaptive, Adjustable |
| Use With - Motion Sensing and Dimming | 1/3 HP Motor, 1/4 HP Motor, Electronic Ballast, Magnetic Ballast |
