mpn:
brand:
manufacturer:
MPN:
Weight:
0.82452885988
Weight:
0.82452885988 LB
Preferred Price:
306.42
Price:
306.42
Min Simple Price:
173.12
Absolute Min Price:
245.83
Min Price:
245.83
Dimensions:
[2.0, 2.0, 1.0]
qty:
21
simpleSku:
MDIwNg:::O2C10-UDW
sku:
MDIwNg::XY:O2C10-UDW@y0
condition:
11
seller:
Zoro
amzMan:
leviton
HazMat:
False
DropShip:
False
Attributes
| Key | Value |
|---|---|
| 07847764274 | UPC |
| Amperage Rating | 60 to 30 mA |
| Application | Commercial |
| Brand | LEVITON |
| Case Pack | 1 |
| Catalog Number | O2C10-UDW |
| Category | Occupant Sensor |
| Ceiling | Mounting |
| Color | White |
| Color - Motion Sensing and Dimming | White |
| Communication Method - Motion Sensing and Dimming | Hard Wired |
| Connection Type | Wired |
| Control Output | Automatic On/Manual On |
| Country of Origin | China, CN |
| Country of Origin (subject to change) | China |
| Coverage | 1000 sq-ft |
| Coverage at Suggested Mounting Height | 1,000 sq ft |
| Description/Special Features | High Inrush Stability, Industry-Exclusive "Fail-Safe" Circuitry, Industry-Exclusive Self-Configuring Local Manual Switch Input, Manual Switch and Emergency Override are Class 1 or Class 2 Circuits. Class 2 Circuits Provided for Flexibility, Output Short Circuit Protection, Presentation Mode Allows User to Turn Lights Off and Keep Them Off While the Room is Occupied, Robust and Reliable Mechanically Held 10a Latching Relay Provides Dependability and Robust Performance for All Load Types and Provides Energy Savings Over Electronically Held Relays, Vacancy Sensing Time Outs |
| Description: | WH ULTRAS CEIL MNT 2RELAY OC SENS 1000' |
| Dimensions | 4.8 in Dia x 2.27 in H |
| For additional options and special quantity discounts, please contact our sales department 1-(855)-296-9508 x 101 or send email to cs@bulbspro.com | Notes |
| Includes | (2) #6-32 Screw, Angled Light Pipe, Emergency Label, Low Voltage Connector, Mounting Plate, Tubing Barrier |
| Installation Location - Motion Sensor | Ceiling |
| Item | Occupancy Sensor |
| Item - Motion Sensing and Dimming | Occupancy Sensor with Photocell |
| Item Type | Occupancy Sensor |
| Leviton | Brand |
| Lighting Technology | Tungsten |
| Made in USA | No |
| Manufacturer | LEVITON, Leviton Manufacturing |
| Max. Capacity @ 120VAC | 800V (Ballast), 800W ( Tungsten), 8A (Electronic Ballast) |
| Max. Capacity @ 277VAC | 6A/6AX (Electronic Ballast, Magnetic Ballast, 1/3 HP Motor) |
| MFG Part #: | O2C10-UDW |
| Mounting | Ceiling |
| Mounting Type | Ceiling |
| Mounting: | Ceiling |
| O2C10-UDW | Stock Code |
| Occupancy & Vacancy Sensors | Family |
| Operating Voltage - Motion Sensing and Dimming | 120/230/277 V AC |
| Response Frequency | 50/60 Hz |
| Sensing Technology | Photocell, Ultrasonic |
| Sensor Type | Ultrasonic |
| Series | O2C |
| Special Features | Ultrasonic |
| Standard | UL 924 listed |
| Standard Pack: | Order QTY must be in multiples of 10 |
| Standard: | UL 924 listed |
| Standards | CA Title 20/24 Compliant, CE Compliant, cUL Listed, NOM Certified, NY LLC48 Compliant, RoHS Compliant, UL 773A, UL 924 |
| Suggested Mounting Height - Motion Sensor | 8 ft to 12 ft |
| Supplier: | LEVITON |
| Temperature Rating | 32 to 104 deg F |
| Time Delay | 30 s to 30 min |
| Time Delay - Motion Sensor | 30 sec to 30 min |
| Time Delay Adjustment Method - Motion Sensor | Adaptive, Adjustable |
| Type | Occupancy Sensor, 2-Pole Dual Relay |
| Type: | Occupancy Sensor |
| UNSPSC | 41111961 |
| UPC | 078477642740 |
| UPC: | 078477642740 |
| Use With - Motion Sensing and Dimming | 1/3 HP Motor, 1/4 HP Motor, Electronic Ballast, Magnetic Ballast |
| Viewing Angle | 360 deg |
| Voltage Rating | 120 to 277 VAC |
| White | Color |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G504393513 | 173.12 | 173.12 | 1 | In Stock | 17 | Leviton | 0.89 | 173.12 @ Qty: 1+ |
| Dale-Electric | O2C10-UDW | 222.42 | 222.42 | 1 | In Stock | Leviton Manufacturing | 222.42 @ Qty: 1+ | |||
| kscdirect.com | LEV O2C10-UDW | 230.06 | 230.06 | 1 | In Stock | LEVITON | 230.06 @ Qty: 1+ | |||
 | Lighting Supply | O2C10-UDW | 237.52 | 237.52 | 1 | In Stock | Leviton | 237.52 @ Qty: 1+ | ||
 | turtle.com | LEV O2C10-UDW | 258.21 | 258.21 | 1 | In Stock | Leviton | 258.21 @ Qty: 1+ | ||
 | Platt.com | 0284725 | 272.65 | 272.65 | 1 | In Stock | Leviton | 272.65 @ Qty: 1+ | ||
 | improvedepot.com | 873557 | 274.5 | 274.5 | 1 | In Stock | Leviton | 274.5 @ Qty: 1+ | ||
 | bulbspro.com | O2C10-UDW | 315.15 | 315.15 | 1 | In Stock | Leviton | 315.15 @ Qty: 1+ | ||
 | crescentelectric.com | 278542 | 329.98 | 329.98 | 1 | In Stock | Leviton | 329.98 @ Qty: 1+ | ||
| us.rs-online.com | 72405095 | 362.07 | 1665.522 | 10 | In Stock | Leviton | 362.07 @ Qty: 10+ |
