| Color - Motion Sensing and Dimming | White |
| Communication Method - Motion Sensing and Dimming | Hard Wired |
| Coverage Angle - Motion Sensor | 180 Degrees |
| Coverage at Suggested Mounting Height | 2,100 sq ft |
| Description/Special Features | Beep Warn - Unit Beeps 3 Times After Delayed-Off Time Expires, then Waits 10 Seconds Before Turning Lights Off, Convenient Dual Pushbuttons Provide Manual-On/Off Light Switching of Each Load At Any Time, Daylight Harvesting Light Sensor Measures the Ambient Light in the Room When it First Detects Motion, Exclusive Leviton H.I.S. Circuitry, Exclusive Walk-Through, False Detection Circuitry, Ground Connection Required. Gangable With Other Devices, Horizontal Field-Of-View May be Adjusted Between 180 Degrees and 60 Degrees Arc by Using Integral Blinders Located on Either Side of the Lens. No Mask-Ing Tape Required, Light Sensor Adjustable Ambient Light Override Ranges From Approximately 2Fc (20 Lux) to 500+Fc (5000+ Lux), Low-Profile Design Eliminates Obtrusive "Scanning-Device" Look, Manual-On/Auto-Off Mode for Installations Where Manual-on Switching is Required But Auto-Off Switching is Still Desired for CEC Title T24 Energy Savings, ODSOD-ID Classroom Mode, ODSOD-ID Conference Room Mode, Presentation Mode, Segmented Fresnel Lens Provides Optimum Sensitivity and Performance. Designed With An Extensive "Minor Motion" Area Where Even Slight Body Movements will be Detected, to Comply With CEC Title 24, Red Led Indicator Light Flashes When PIR Sensor Detects Motion to Verify Detection is Active, Unit Fits in Standard Single-Gang Wallbox and Replaces Two Single-Pole Wall Switches, Vandal Resistant PIR Lens |
| Includes | Photocell |
| Installation Location - Motion Sensor | Wall Switch Box |
| Item, Item - Motion Sensing and Dimming | Occupancy Sensor |
| Lighting Technology | Fluorescent, Incandescent |
| Max. Capacity @ 120VAC | 1200V (Primary Relay Fluorescent), 800V (Secondary Relay Fluorescent), 800W (Incandescent) |
| Max. Capacity @ 277VAC | 2700V (Primary Relay Fluorescent) |
| Operating Voltage - Motion Sensing and Dimming | 120/230/277 V AC |
| Sensing Technology | Passive Infrared |
| Standards | cUL/US Certified, FCC Compliant, Title 24, Part 6 |
| Time Delay - Motion Sensor | 30 sec to 30 min |
| Time Delay Adjustment Method - Motion Sensor | Adaptive, Adjustable |
