mpn:
brand:
manufacturer:
MPN:
Weight:
1.55
Weight:
1.55 LB
Preferred Price:
102.37
Price:
102.37
Min Simple Price:
55.94
Absolute Min Price:
79.43
Min Price:
79.43
Dimensions:
[3.0, 3.0, 3.0]
qty:
21
simpleSku:
MDY0Mg:::68514476524
sku:
MDY0Mg::64:68514476524@y0
condition:
11
seller:
AmazonSC
amzMan:
lovejoy
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Angular Displacement | 0.050 in |
| Bore Size | 1 in |
| Color | Metallic |
| Coupling Size | 28 |
| Coupling Type | Jaw |
| Cubic inches | 9.04397 in3 |
| Description: | CJ28/38B-HUB-PM-1"-NKW; |
| Dimension G | 0.790 in (20.07 mm) |
| Dimension HD, Outside Diameter | 2.560 in (65.02 mm) |
| Distance between Spider and Hub Face (Dimension CL) | 0.100 in (2.54 mm) |
| Hub Material | Powder Metal |
| Hub Style | B |
| Keyway Size (W x D) | No Keyway in |
| Length thru Bore (Dimensions LTB1/LTB2) | 1.380 in (35.05 mm) |
| Manufacturer, Supplier: | LOVEJOY INC |
| Max Torque (with 92 Shore A spider) | 1680.00 in-lb |
| Max. Angular Displacement (Ka), n=1500 [1/min] | 0.90 ? |
| Max. Axial Displacement (Ka) | 0.0600 in |
| Max. Bore (Dimensions ID1/ID2) | 1.5 in (38 mm) |
| Max. Radial Displacement (Kr) | 0.0100 in |
| Max. Speed | 8500.00 rpm |
| Max. Temperature Range (with 80 Shore A, 92 Shore A, and 95/98 Shore A spiders) | -50 to 248 ?F |
| MFG Part #: | 68514476524 |
| Min. Bore (Dimensions ID1/ID2) | 0.870 in (22.00 mm) |
| Nominal Torque (with 92 Shore A spider) | 840.00 in-lb |
| Normal Temperature Range (with 80 Shore A, 92 Shore A, and 95/98 Shore A spiders) | -40 to 212 ?F |
| Overall Coupling Length | 3.540 in (89.92 mm) |
| Set Screw Style Coupling Location Size (Dimension SL) | 0.590 in (14.99 mm) |
| Set Screw Style Coupling Size (Dimension T) | 5/16-18 |
| Spider Outside Diameter | 2.560 in (65.00 mm) |
| Spider Thickness (Dimension W) | 0.590 in (15.00 mm) |
| Style | Bored |
| Type | Curved Jaw Coupling Hubs |
| UPC: | 685144765246 |
| Weight | 1.55 lb |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| AmazonSC | B004QX0264 | 55.94 | 55.94 | 1 | In Stock | Lovejoy | 55.94 @ Qty: 1+ | |||
 | Megadepot | 68514476524 | 92.29 | 92.29 | 1 | In Stock | Lovejoy | 1.55 | 92.29 @ Qty: 1+ | |
 | heavydutydepot.com | 68514476524 | 92.29 | 129.206 | 2 | In Stock | Lovejoy | 92.29 @ Qty: 2+ | ||
 | usmegastore.com | 68514476524 | 95.64 | 95.64 | 1 | In Stock | Lovejoy | 1.55 | 95.64 @ Qty: 1+ | |
| kscdirect.com | LOV 68514476524 | 119.46 | 119.46 | 1 | In Stock | LOVEJOY INC | 119.46 @ Qty: 1+ | |||
 | midwestapplianceparts.com | 68514476524-LJ-P | 150.29 | 150.29 | 1 | In Stock | Lovejoy | 150.29 @ Qty: 1+ |
