- mpnTR-50522-12
- brandname: MACROMATIC
- manufacturername: MACROMATIC
Time Dlay Rlay, 120VAC/DC, 10A, DPDT, 3 sec.
- Brand: Macromatic
- PartNumber: TR-50522-12
- Model: TR-50522-12
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: MACROMATIC
- Label: MACROMATIC
Attributes
| Key | Value |
|---|
| AC Contact Rating - Rel. | 10 A @ 240V, 10A @ 240V |
| Adjustment Method - Tim. | Potentiometer |
| Base Type - Plug In Rel. | Octal |
| Body Depth | 2.9 in |
| Body Depth - Relay | 1.70 in, 1.7 in |
| Body Height | 1.7 in |
| Body Height - Relay | 2.9 in, 2.90 in |
| Body Width | 2.3 in |
| Body Width - Relay | 2.40 in, 2.4 in |
| Brand | Macromatic |
| Coil Volts | 120V AC/DC |
| Color | White |
| Contact Form - Relay | DPDT |
| Contact Material | Silver Nickel |
| Current Stock | 16 |
| DC Contact Rating - Rel. | 10A @ 30V, 10 A @ 30V |
| Electrical Connection | Socket |
| Flat Pin Width | Not Applicable |
| Function - Timing Relay | Interval On |
| Gross Weight | 0 lbs |
| Hz - Electrical | 50 Hz, 60 Hz |
| International Shipping | No |
| Item - Relay | Single Function Timing . |
| Max. Time Setting - Tim. | 5 min |
| Min. Time Setting - Tim. | 3.00 sec, 3 sec |
| Mounting - Relay | Plug In, Plug-In |
| Mpn | TR-50522-12 |
| Number of Pins - Relay | 8 |
| Overall Depth | 3.5 in |
| Overall Height - Relay | 3.10 in, 3.1 in |
| Pins | 8 |
| Power Consumption - Rel. | 2.5 VA, 2.0 W, 2 W, 2.5. |
| SKU | ZO-G5268024 |
| Socket | 5X852, 1EGP3, 1EGP5 |
| Standards | UR, CSA, CE |
| Status Indicator | None |
| SubCategory | Electrical |
| UPC | 801262045132 |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Zoro | G5268024 | 22.99 | 1 | 24 | | Macromatic | 0.25 | 22.99 @ 1 |
| grainger.ca | WWG23NU95 | 30.80320664 | 1 | In Stock | | MACROMATIC | 0.25 | 30.80320664 @ 1 |
 | Raptor Supplies | AB7KKB | 54.258516 | 1 | In Stock | | MACROMATIC | | 54.258516 @ 1 |
 | sustainablesupply.com | C1173772 | 55.05 | 1 | In Stock | | Macromatic | 0.25 | 55.05 @ 1 |
 | National Supply Network | 77981595 | 57.84 | 1 | In Stock | | Macromatic | | 57.84 @ 1 |
 | simsupply.com | ZO-G5268024 | 64.43 | 1 | 16 | | Macromatic | | 64.43 @ 1 |
 | bscsource.com | TR5052212 | 64.99 | 1 | In Stock | | Macromatic | | 64.99 @ 1 |
 | blackhawksupply.com | TR-50522-12 | 72.14 | 1 | In Stock | | Macromatic | | 72.14 @ 1 |
 | Walker Industrial | TR-50522-12 | 73.99 | 1 | In Stock | 17 | Macromatic | | 73.99 @ 1 |
 | Galco | TR-50522-12-MCRM | 89.5 | 1 | In Stock | | Macromatic | | 89.5 @ 1 |
 | Newark | 28B3568 | 129.85 | 1 | In Stock | | MACROMATIC CONTROLS | | 129.85 @ 1 |
