mpn:
brand:
manufacturer:
MPN:
Description:
Amps: 19.6Bearings: BallDuty Cycle: ContinuousEfficiency: 0.816Enclosure Material: SteelEnclosure Type: ODP (Open Dripproof)Frame: 56HHP: 5Hz: 60Insulation Class: FManufacturer Model #: 5KCR49ZN2722YMaximum Ambient Temperature: 40? CMotor Diameter: 6-1/2"Motor Shell Length: 10.71"Mounting Orientation: AnyMounting: Base
Attributes
| Key ^ | Value |
|---|---|
| Amps | 19.6 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.816 |
| Enclosure Material | Steel |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 56H |
| HP | 5 |
| Hz | 60 |
| Insulation Class | F |
| Manufacturer Model # | 5KCR49ZN2722Y |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 6-1/2" |
| Motor Shell Length | 10.71" |
| Mounting | Base |
| Mounting Orientation | Any |
| Number of Speeds, Phase, Service Factor | 1 |
| Overall Length | 15.04" |
| Product Type | Capacitor Start/Capacitor Run |
| Rotation | Reversible |
| RPM | 3450 |
| Shaft Diameter | 5/8" |
| Shaft Length | 1.88" |
| Ship Weight | 50 lbs. |
| Thermal Protection | Manual |
| Volts | 230 |
