Description:
Amps: 0.7Bearings: BallDuty Cycle: ContinuousEfficiency: 0.782Enclosure Material: SteelEnclosure Type: ODP (Open Dripproof)Frame: 56HP: 1/2Hz: 60Insulation Class: BManufacturer Model #: 056T17D11043Maximum Ambient Temperature: 40? CMotor Diameter: 6-1/2"Mounting Orientation: HorizontalMounting: BASENUMBER of Speeds: 1O
Attributes
| Key ^ | Value |
|---|---|
| Amps | 0.7 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.782 |
| Enclosure Material | Steel |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 56 |
| HP | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Manufacturer Model # | 056T17D11043 |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 6-1/2" |
| Mounting | Base |
| Mounting Orientation | Horizontal |
| Number of Speeds | 1 |
| Overall Length | 11.31" |
| Phase | 3 |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1725 |
| Service Factor | 1.25 |
| Shaft Diameter | 5/8" |
| Shaft Length | 1.88" |
| Ship Weight | 31 lbs. |
| Volts | 575 |
