Description:
Amps: 4.6/2.3Bearings: BallDuty Cycle: ContinuousEfficiency: 0.865Enclosure Material: SteelEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Frame: 56HCHP: 1-1/2Hz: 60Insulation Class: FManufacturer Model #: 056T17F15641Maximum Ambient Temperature: 40? CMotor Shell Length: 9.15"Mounting Orientation: Horizontal/Vertical
Attributes
| Key ^ | Value |
|---|---|
| Amps | 4.6/2.3 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.865 |
| Enclosure Material | Steel |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Frame | 56HC |
| HP | 1-1/2 |
| Hz | 60 |
| Insulation Class | F |
| Manufacturer Model # | 056T17F15641 |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 9.15" |
| Mounting | Face/Base |
| Mounting Orientation | Horizontal/Vertical |
| Number of Speeds | 1 |
| Overall Length | 14.15" |
| Phase | 3 |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1725 |
| Service Factor | 1.15 |
| Shaft Diameter | 5/8" |
| Shaft Length | 1.88" |
| Ship Weight | 45 lbs. |
| Volts | 230, 460 |
