Description:
Amps: 3-3.2/1.6Bearings: BallDuty Cycle: ContinuousEfficiency: 0.74Enclosure Material: IronEnclosure Type: EPFC (Explosion Proof Fan Cooled)Frame: 143THP: 3/4Hz: 60Insulation Class: BManufacturer Model #: 143TTGN7076Maximum Ambient Temperature: 40? CMotor Shell Length: 5.25"Mounting Orientation: HorizontalMounting: Bas
Attributes
| Key ^ | Value |
|---|---|
| Amps | 3-3.2/1.6 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.74 |
| Enclosure Material | Iron |
| Enclosure Type | EPFC (Explosion Proof Fan Cooled) |
| Frame | 143T |
| HP | 3/4 |
| Hz | 60 |
| Insulation Class | B |
| Manufacturer Model # | 143TTGN7076 |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 5.25" |
| Mounting | Base |
| Mounting Orientation | Horizontal |
| Number of Speeds | 1 |
| Overall Length | 12.48" |
| Phase | 3 |
| Product Type | Three Phase |
| Rotation | Reversible |
| RPM | 1145 |
| Service Factor | 1.15 |
| Shaft Diameter | 7/8" |
| Shaft Length | 2.31" |
| Ship Weight | 55 lbs. |
| Volts | 208, 230, 460 |
