Amps: 5.2/2.7-2.6Bearings: BallDuty Cycle: ContinuousEfficiency: 0.732Enclosure Material: SteelEnclosure Type: TENV (Totally Enclosed Non Ventilated)Frame: 56HP: 1/2Hz: 60Insulation Class: BManufacturer Model #: 5KHC39QN9584XMaximum Ambient Temperature: 40? CMotor Diameter: 6-1/2"Motor Shell Length: 6.22"Mounting Orien
Attributes
| Key ^ | Value |
|---|---|
| Amps | 5.2/2.7-2.6 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.732 |
| Enclosure Material | Steel |
| Enclosure Type | TENV (Totally Enclosed Non Ventilated) |
| Frame | 56 |
| HP | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Manufacturer Model # | 5KHC39QN9584X |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 6-1/2" |
| Motor Shell Length | 6.22" |
| Mounting | Base |
| Mounting Orientation | Any |
| Number of Speeds, Phase | 1 |
| Overall Length | 10.37" |
| Product Type | Split Phase Start/Capacitor Run |
| Rotation | Reversible |
| RPM | 1725 |
| Service Factor | 1.3 |
| Shaft Diameter | 5/8" |
| Shaft Length | 1.88" |
| Ship Weight | 19 lbs. |
| Thermal Protection | Automatic |
| Volts | 115, 208, 230 |
