Amps: 3.0/1.6-1.5Bearings: BallDuty Cycle: ContinuousEfficiency: 0.68Enclosure Material: SteelEnclosure Type: TENV (Totally Enclosed Non Ventilated)Frame: 48HP: 1/4Hz: 60Insulation Class: BManufacturer Model #: 5KHC39QN9575TMaximum Ambient Temperature: 40? CMotor Diameter: 5-5/8"Motor Shell Length: 6.62"Mounting Orient
Attributes
| Key ^ | Value |
|---|---|
| Amps | 3.0/1.6-1.5 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.68 |
| Enclosure Material | Steel |
| Enclosure Type | TENV (Totally Enclosed Non Ventilated) |
| Frame | 48 |
| HP | 1/4 |
| Hz | 60 |
| Insulation Class | B |
| Manufacturer Model # | 5KHC39QN9575T |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 5-5/8" |
| Motor Shell Length | 6.62" |
| Mounting | Base |
| Mounting Orientation | Any |
| Number of Speeds, Phase, Service Factor | 1 |
| Overall Length | 10.4" |
| Product Type | Split Phase Start/Capacitor Run |
| Rotation | Reversible |
| RPM | 1725 |
| Shaft Diameter | 1/2" |
| Shaft Length | 1.5" |
| Ship Weight | 16 lbs. |
| Thermal Protection | Automatic |
| Volts | 115, 208, 230 |
