Amps: 5.5-5.6/2.7-2.8Bearings: BallDuty Cycle: ContinuousEfficiency: 0.62Enclosure Material: SteelEnclosure Type: ODP (Open Dripproof)Frame: 48YZHP: 1/3Hz: 60Insulation Class: BManufacturer Model #: 5KH33GNA444XMaximum Ambient Temperature: 40? CMotor Diameter: 5-5/8"Motor Shell Length: 5.41"Mounting Orientation: AnyMou
Attributes
| Key ^ | Value |
|---|---|
| Amps | 5.5-5.6/2.7-2.8 |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Efficiency | 0.62 |
| Enclosure Material | Steel |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 48YZ |
| HP | 1/3 |
| Hz | 60 |
| Insulation Class | B |
| Manufacturer Model # | 5KH33GNA444X |
| Maximum Ambient Temperature | 40? C |
| Motor Diameter | 5-5/8" |
| Motor Shell Length | 5.41" |
| Mounting | Base |
| Mounting Orientation | Any |
| Number of Speeds, Phase, Service Factor | 1 |
| Overall Length | 7.94" |
| Product Type | Split Phase |
| Rotation | Reversible |
| RPM | 1725 |
| Shaft Diameter | 5/8" |
| Shaft Length | 0.17" |
| Ship Weight | 14 lbs. |
| Thermal Protection | Automatic |
| Volts | 120, 200, 100, 240 |
