mpn:
brand:
manufacturer:
MPN:
Weight:
2.359375
Weight:
2.359375 LB
Preferred Price:
1677.12
Price:
1677.12
Min Simple Price:
947.53
Absolute Min Price:
1345.49
Min Price:
1345.49
Dimensions:
[14.0, 6.0, 6.0]
qty:
21
simpleSku:
NDY2MA:::056E17V2003
sku:
NDY2MA::JZ:056E17V2003@y0
condition:
11
seller:
Purvis
amzMan:
marathon motors
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Base Mounting O.C. | 3 in x 4-22/25 in |
| Bearings, Motor Bearings | Ball |
| Body Dia. | 5.6 in |
| Bolt Circle Dia. | 5 7/8 in |
| Brush Type | Carbon |
| Category | Electric Motor |
| Conduit Box Location | Exterior |
| Country of Origin (subject to change) | United States |
| Duty Cycle | Continuous |
| Efficiency %, Nominal Efficiency | 81.1 % |
| Enclosure | Totally Enclosed Non-Ventilated, TENV |
| Face Mounting O.C. | (4) Locating Screws 90 Degrees Apart |
| Family Series | Marathon Electric Motors |
| Features, Frame Remarks, Motor Application | Washdown |
| Finish | Enamel |
| Frame | 56C |
| Frame Remarks, Mounting Type | Footed |
| Full Load Amps | 5.0 |
| Full Load Torque | 18 lb-in |
| Gross Weight | 0 lbs |
| Horsepower | 1/2 hp |
| HP | 0.50, 1/2 |
| Ins. Class | F |
| Item Condition | FACTORY NEW |
| Item Number | 056E17V2003 |
| Item, Product Type | Washdown Motor |
| Kilowatts | 0.37 kW |
| Length Less Shaft | 11 1/4 in |
| Manufacturer | Marathon Electric |
| Manufacturer Part Number | Z634 |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Design | Permanent Magnet DC |
| Motor Enclosure Design | Totally Enclosed Nonventilated |
| Motor Mounting Type | Face/Base, Rigid Base |
| Motor Service Factor, No. of Speeds, Service Factor | 1 |
| Motor Shaft Rotation | CCWLE |
| Motor Thermal Protection | None |
| mounting | C-face w/ rigid base |
| Nameplate RPM | 1,750 |
| NEMA Frame | S56C |
| Net Weight | 37 lbs |
| Overall Length | 13 3/16 in |
| Phase | C |
| Rotation | CW/CCW |
| RPM | 1750, 1,750 RPM |
| RPM Range | 1,701-1,800 |
| Shaft Dia. | 5/8 in |
| Shaft Length | 1 15/16 in |
| Shaft Material | Stainless Steel |
| Standards | UL(E49747) CSA(E49747) |
| Usable @ 200V, Usable @ 208V | No |
| Voltage, Voltage Compatibility | 90V DC |
| Volts | 90 |
| Weight | 37 lb |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Purvis | Z634 | 947.53 | 947.53 | 1 | In Stock | Marathon | 947.53 @ Qty: 1+ | ||
 | Zoro | G6908377 | 956.92 | 956.92 | 1 | In Stock | 26 | Marathon Motors | 37.0 | 956.92 @ Qty: 1+ |
 | Galco | 056E17V2003-MARA | 972.5 | 972.5 | 1 | In Stock | Marathon Electric | 37.0 | 972.5 @ Qty: 1+ | |
 | Dealers Electric | 056E17V2003 | 1038.99 | 1038.99 | 1 | In Stock | Marathon Electric | 37.0 | 1038.99 @ Qty: 1+ | |
 | sustainablesupply.com | C1550066 | 1293.19 | 1293.19 | 1 | In Stock | Marathon | 37.75 | 1293.19 @ Qty: 1+ | |
| grainger.ca | WWG26VU27 | 1327.4265934 | 1327.4265934 | 1 | In Stock | MARATHON MOTORS | 37.75 | 1327.4265934 @ Qty: 1+ |
