mpn:
brand:
manufacturer:
MPN:
Weight:
202.0
Weight:
12.5625 LB
Preferred Price:
2239.63
Price:
2239.63
Min Simple Price:
1265.33
Absolute Min Price:
1796.76
Min Price:
1796.76
Dimensions:
[20.0, 2.0, 2.0]
qty:
21
simpleSku:
NDY2MA:::215TTFS6576
sku:
NDY2MA::G7:215TTFS6576@y0
condition:
11
seller:
Zoro
amzMan:
marathon motors
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| CC Number | CC003A |
| Classification | Blue Chip Severe Duty Automotive Duty |
| Country of Origin (subject to change) | United States |
| Duty | Continuous |
| Enclosure | TEFC |
| Frame | 215T |
| Frame Material, Motor Frame Material | Cast Iron |
| Frame Remarks | Rigid |
| Full Load Amps | 6.9 |
| HP | 5 |
| Hz | 60 |
| Includes | Max Guard Insulation |
| Ins. Class | F |
| Item | Severe Duty Motor |
| Item Condition | Factory New |
| Length Less Shaft | 16-3/16" |
| Manufacturer | Marathon Electric |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Efficiency Group | NEMA Premium Efficient |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Nameplate RPM | 1170 |
| No. of Speeds | 1 |
| Nominal Efficiency | 91.7% |
| Overall Length | 19-3/4" |
| Phase | 3 |
| RPM | 1200 |
| RPM Group, RPM Range | 1101-1200 |
| Shaft Dia. | 1-3/8" |
| Shaft Length | 3-9/16" |
| Standards | UL (E49747), CSA (LR2025) |
| Voltage | 230/460 |
| Voltage Compatibility | 460, 208-230/460 |
| Volts | 460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G9943945 | 1265.33 | 1265.33 | 1 | In Stock | 26 | Marathon Motors | 1265.33 @ Qty: 1+ | |
 | Dealers Electric | 215TTFS6576 | 1832.9 | 1832.9 | 1 | In Stock | Marathon Electric | 201.0 | 1832.9 @ Qty: 1+ |
