mpn:
brand:
manufacturer:
MPN:
Weight:
26.4375
Weight:
26.4375 LB
Preferred Price:
3788.31
Price:
3788.31
Min Simple Price:
2140.29
Absolute Min Price:
3039.21
Min Price:
3039.21
Dimensions:
[27.0, 2.0, 2.0]
qty:
21
simpleSku:
jEzMjc:::284TTDBD6033
sku:
jEzMjc::YC:284TTDBD6033@y0
condition:
11
seller:
Zoro
amzMan:
marathon electric / regal beloit
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Category | Electric Motor |
| CC Number | CC003A |
| Composition | Rolled Steel |
| Country of Origin (subject to change) | China |
| Duty | Continuous |
| Efficiency % | 93.6 % |
| Enclosure | ODP, Open |
| Family Series | Marathon Electric Motors |
| Frame Material, Motor Frame Material | Cast Iron |
| Frame Remarks | 575 VOLT |
| Frame Remarks, Mounting Type | Footed |
| Frame, NEMA Frame | 284JM |
| Full Load Amps | 24.8 |
| Gross Weight | 0 lbs |
| Horsepower | 25 hp |
| HP | 25 |
| Hz | 60 |
| Ins. Class | F |
| Inverter Rated | Yes |
| Item | Close-Coupled Pump Motor |
| Item Condition | FACTORY NEW |
| Item Number | 284TTDBD6033 |
| Kilowatts | 18.7 kW |
| Length Less Shaft | 21-5/16" |
| Manufacturer | Marathon Electric |
| Manufacturer Part Number | GT0565 |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | Pump |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Efficiency Group | NEMA Premium Efficient |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Type | Face/Base |
| Motor Service Factor, Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Close-Coupled Pump |
| Motor Thermal Protection | None |
| mounting | C-face w/ rigid base |
| Nameplate RPM | 1778 |
| Net Weight | 423 lbs |
| Nominal Efficiency | 94.1% |
| Nominal Voltage, Voltage (AC) | 575 VAC |
| Overall Length | 26-9/16" |
| Phase | 3 |
| RPM | 1,775 RPM, 1800 |
| RPM Range | 1701-1800 |
| Shaft Dia. | 1-1/4" |
| Shaft Length | 5-1/4" |
| Standards | UL Recognized (E49747), CSA Certified (LR2025) |
| Voltage, Voltage Compatibility, Volts | 575 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G9824184 | 2140.29 | 2140.29 | 1 | In Stock | 25 | Marathon Motors | 2140.29 @ Qty: 1+ | |
 | Galco | 284TTDBD6033-MARA | 2981.0 | 2981.0 | 1 | In Stock | Marathon Electric | 423.0 | 2981.0 @ Qty: 1+ | |
 | Dealers Electric | 284TTDBD6033 | 3333.16 | 3333.16 | 1 | 3 | Marathon Electric | 423.0 | 3333.16 @ Qty: 1+ | |
 | pumpproducts.com | 284TTDBD6033 | 4519.58 | 4519.58 | 1 | In Stock | Marathon | 4519.58 @ Qty: 1+ |
