| Ambient Temperature | 40 Degrees C |
| CC Number | CC003A |
| Country of Origin (subject to change) | United States |
| Duty | Continuous |
| Finish | Enamel |
| Frame | 324HPV |
| Full Load Amps | 77.0/38.5 |
| HP | 30 |
| Hz | 60 |
| Ins. Class | F |
| Item | Vertical Pump Motor |
| Length Less Shaft | 31-1/8" |
| Motor Application | Pump |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Frame Material | Cast Iron |
| Motor Mounting Position | Vertical Shaft Down |
| Motor Mounting Type | Face |
| Motor Service Factor | 1.15 |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Vertical Pump |
| Motor Thermal Protection | None |
| Nameplate RPM | 1180 |
| NEMA Standard | MG-1 18.238.1 |
| Nominal Efficiency | 94.5% |
| Overall Length | 35-5/8" |
| Phase | 3 |
| RPM Range | 1101-1200 |
| Shaft Dia. | 1-5/8" |
| Shaft Length | 4-1/2" |
| Standards | UL (E49747), CSA (LR2025) |
| Voltage | 230/460 |
| Voltage Compatibility | 460, 230/460, 220-230/460 |
| Warranty | 1 yr. |
