Attributes
| Key | Value |
|---|---|
| Application | Washguard |
| Body Dia. | 6-1/2" |
| Classification | PowerWash XT Washdown Duty |
| Composition | Rolled Steel |
| Conduit Box | Cast Oversized Gasketed |
| Country of Origin (subject to change) | Mexico |
| Drain Plugs | (2) Drain Plugs in Conduit Box , (4) Drain Plugs in Each End Bells |
| Duty | Continuous |
| Efficiency % | 78.5 % |
| Enclosure | Totally Enclosed Non-Ventilated, TENV |
| Endshields | Cast Aluminum |
| Family Series | Marathon Electric Motors |
| Frame | 56 |
| Frame Material | Epoxy Coated |
| Frame Remarks | Rigid |
| Full Load Amps | 1.2/.6 |
| Gross Weight | 0 lbs |
| Horsepower | 1/3 hp |
| HP | .33, 1/3 |
| Hz | 60/50 |
| Includes | Shaft Seal and V-Ring, Stainless Steel Shaft, Hardware and Nameplate |
| Ins. Class | F |
| Inverter Rated | Yes |
| Item | Washdown Motor |
| Item Condition | Factory New |
| Item Number | 5KS49HN4595 |
| Kilowatts | 0.25 kW |
| Length Less Shaft | 7-3/4" |
| Manufacturer | Marathon Electric |
| Manufacturer Part Number | E286 |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | Washdown |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Nonventilated |
| Motor Frame Material | Epoxy Coated Rolled Steel |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.35 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting Type | Footed |
| Nameplate RPM | 1725 |
| NEMA Design | B |
| NEMA Frame | 56 |
| Net Weight | 24 lbs |
| Nominal Efficiency | 87.5% |
| Nominal Voltage | 208 VAC, 240 VAC, 277 VAC, 347 VAC, 380 VAC, 415 VAC, 480 VAC |
| Overall Length | 9-11/16" |
| Phase | 3 |
| RPM | 1800, 1,725 RPM |
| RPM Range | 1701-1800 |
| Service Factor | 1.35 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1-15/16" |
| Shaft Material | 303 Stainless Steel |
| Standards | UL(E49747), CSA(LR2025) |
| Voltage | 208-230/460 |
| Voltage (AC) | 208 VAC, 230 VAC, 460 VAC |
| Voltage Compatibility | 208, 230, 240, 460, 208-220/440, 208-230, 208-230/460, 208-240, 220/460, 220-230/460, 230/460 |
| Volts | 208-230/460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Galco | 5KS49HN4595-MARA | 149.17 | 149.17 | 1 | In Stock | Marathon Electric | 24.0 | 149.17 @ Qty: 1+ | |
 | Dealers Electric | 5KS49HN4595 | 412.84 | 412.84 | 1 | In Stock | Marathon Electric | 25.0 | 412.84 @ Qty: 1+ | |
 | Raptor Supplies | AF8LCU | 523.1991375 | 523.1991375 | 1 | In Stock | MARATHON MOTORS | 523.1991375 @ Qty: 1+ | ||
 | Zoro | G5667803 | 605.44 | 605.44 | 1 | In Stock | Marathon Motors | 605.44 @ Qty: 1+ |
