mpn:
brand:
manufacturer:
MPN:
Description:
Martin Sprocket & Gear manufactures power transmission products, material handling components, and industrial hand tools. The company, founded in 1951 and headquartered in Arlington, TX, meets International Organization for Standardization (ISO) standard 9001:2008.</p></div>
Weight:
2.97
Weight:
2.97 LB
Preferred Price:
316.29
Price:
316.29
Min Simple Price:
178.7
Absolute Min Price:
253.75
Min Price:
253.75
Dimensions:
[4.0, 4.0, 3.0]
qty:
21
simpleSku:
AzNTky:::B004BDOCI8
sku:
AzNTky::I8:B004BDOCI8@y0
condition:
11
seller:
industrialzone.com
amzMan:
martin
HazMat:
False
DropShip:
True
Attributes
| Key | Value |
|---|---|
| Bore Type | Reboreable |
| bore type: | Plain |
| Country of Origin (subject to change) | United States |
| Diametral Pitch | 8 |
| Face Width | 0.75 |
| gear overall width: | 2-3/32 in |
| Gear Ratio | 0.0423611111111111 |
| Gear Type | Right Angle Drive |
| Hub Dia. | 2.5 |
| hub diameter: | 2-1/2 in |
| Hub Projection (In.) | 1.25 |
| hub projection: | 1-1/4 in |
| hub type: | No Screws |
| Length through Bore | 2.09375 |
| Manufacturer Number | 1 |
| Material | Steel |
| material: | Steel |
| Mating Gear | M627, M627A, HM627, HM627A, HMK627A, HMK627, HMK824, HMK824A, HMK824B |
| Max. Bore | 1.439 |
| Min. Bore | 1 |
| Mounting Distance | 3.25 |
| mounting distance: | 3-1/4 in |
| Number Of Teeth | 28 |
| Outside Dia | 3.677" |
| Outside Diameter | 3.677 |
| Pitch Diameter | 3.5 |
| pitch: | 8 |
| Pressure Angle | 20 |
| pressure angle: | 20 |
| standards met: | ANSI B15.1 |
| steel hardening: | Hardened Teeth |
| Storage Height | 2.09375 |
| Storage Length | 3.677 |
| Storage Width | 3.677 |
| tooth type: | Straight |
| Weight | 2.97 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | industrialzone.com | HM828 | 178.7 | 250.18 | 2 | In Stock | Martin | 1.0 | 178.7 @ Qty: 2+ | |
 | cbtcompany.com | HM828 | 195.39 | 195.39 | 1 | In Stock | Martin Sprocket & Gear | 195.39 @ Qty: 1+ | ||
 | motionindustries.com | 00373060 | 196.04 | 196.04 | 1 | In Stock | Martin | 196.04 @ Qty: 1+ | ||
 | MRO Supply | 250971 | 214.03 | 214.03 | 1 | In Stock | Martin Sprocket | 214.03 @ Qty: 1+ | ||
 | apexindustrialautomation.com | HM828 | 232.64 | 232.64 | 1 | 4 | Martin Sprocket | 232.64 @ Qty: 1+ | ||
 | Zoro | G3316648 | 255.0 | 255.0 | 1 | In Stock | Martin Sprocket & Gear | 2.97 | 255.0 @ Qty: 1+ | |
 | Purvis | HM828 | 262.06 | 262.06 | 1 | In Stock | Martin | 262.06 @ Qty: 1+ |
