| AC connection | universal |
| Alarms | 4 alarm modes |
| Approvals | CE, E-mark, ABYC A-31 |
| Continuous power at 25 ?C, 77 ?F, cos phi 1 | 500 W |
| Continuous power at 40 ?C, 104 ?F, cos phi 1 | 400 W |
| Cooling | natural/forced |
| Cos phi | all power factors allowed |
| Display/read-out | LED display |
| Efficiency | 90 % |
| Harmonic distortion typical | < 6 % |
| High battery voltage, switches off at | 16 V, ? 0.5 V |
| High battery voltage, switches on at | 14.5 V, ? 0.5 V |
| Input current (nominal load) | 37.5 A |
| Low battery voltage, switches off at | 10 V, ? 0.5 V |
| Low battery voltage, switches on at | 11 V, ? 0.5 V |
| MasterBus compatible | no |
| Max. ripple on DC (battery) | 10 % RMS |
| Minimal cable size | 1.5 mtr DC cable delivered as standard |
| Minimal DC fuse (slow blow) | 2x 40 A |
| No-load power consumption (energy saving mode) | 0.33 A - 4 W |
| No-load power consumption (ON mode) | 0.58 A ? 7 W |
| Nominal battery voltage | 12 V |
| Output voltage | 230 V - 50 Hz (? 0.1%) |
| Output waveform | true sine |
| Peak load | 800 W |
| Protection degree | IP23, vertical wall mounting |
| Protections | over temperature, over load, short circuit, high/low battery voltage |
| Recommended battery capacity | ? 100 Ah |
| Technology | high frequency, input & output fully isolated |
