| [Iu] Rated Interrupted Current | 65 kA |
| [Ue] Rated Operational Voltage | 480Y/277 V AC |
| California Proposition 65 : WARNING: This product can expose you to chemicals including | Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
| Circuit Breaker Type | EDB/EDG/EDJ |
| Enclosure Nominal Depth | 5.65 in NEMA 1 |
| Enclosure Nominal Height | 85 in |
| Enclosure Nominal Width | 8.625 in |
| Environmental Disclosure | ENVPEP1404020EN |
| Eu Rohs Directive | Compliant |
| Height | 71 in |
| Line Rated Current | 225 A |
| Load Center Type | main breaker |
| Material | copper |
| Mercury Free, Reach Free Of Svhc, Rohs Exemption Information, Toxic Heavy Metal Free | Yes |
| Number Of Spaces | 42 |
| Phase | 3 phase |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Standards | CSA || UL |
| Sustainable Offer Status | Green Premium product |
| Tightening Torque | 4.52-5.65 N.m 13.30-67.43 mm? (AWG 6...AWG 2/0) || 11.3-11.3 N.m 13.30-67.43 mm? (AWG 6...AWG 2/0) || 31.07-31.07 N.m 13.30-177.3 mm? (AWG 6...350 kcmil) || 31.07-31.07 N.m 13.30-126.7 mm? (AWG 6...250 kcmil) || 31.07-31.07 N.m 107.2-152 mm? (AWG 4...300 kcmil) |
| Warranty | 18 months |
| Width | 10.44 in |
| Wiring Configuration | 4-wire |
