| ARRA Compliant, Buy American Compliant | Y |
| Body Material | ABS/Polycarbonate |
| Color | Green |
| Connector Type, Product Type | Jack Module |
| Contact Material | Plated Phosphor Bronze |
| Country of Origin 2Digit | US |
| EAN, GTIN Package | 00074983997152 |
| GTIN Carton | 50074983997157 |
| Hazardous Material Flag | N |
| Maximum Operating Temperature (?C) | 65 |
| Maximum Operating Temperature (?F) | 149 |
| Maximum Storage Temperature (?C) | 70 |
| Maximum Storage Temperature (?F) | 158 |
| Mercury Content Indicator | No |
| Min Order Qty, Std. Pkg. Qty. | 25 |
| Min. Order UOM, Std. Pkg. UOM | Piece |
| Minimum Operating Temperature (?C) | -10 |
| Minimum Operating Temperature (?F) | 14 |
| Module Type | Keystone |
| Note | Punchdown style termination; convenience pack of 25 |
| Overall Depth (In.), Overall Length (In.) | 1.16 |
| Overall Depth (mm), Overall Length (mm) | 29.5 |
| Overall Height (In.) | 0.9 |
| Overall Height (mm) | 22.9 |
| Overall Width (In.) | 0.65 |
| Overall Width (mm) | 16.5 |
| Pallet Quantity | 35,750 |
| Pallet Volume | 49.559739 |
| Pallet Weight | 643.5000 |
| Performance Level | Category 6 |
| Product Segment | EDI-ENT |
| REACH Status | False |
| RoHS Compliant | Compliant |
| Shield Type | Unshielded (UTP) |
| Standard Carton Volume Ft3 | 0.3466 |
| Standard Carton Weight Pounds | 4.5000 |
| Standard Package Volume Ft3 | 0.0347 |
| Standard Package Weight Pounds | 0.4500 |
| Standards Met | Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant. |
| Std Carton Height In | 4.55 |
| Std Carton Height MM | 115.57 |
| Std Carton Length In | 13.2 |
| Std Carton Length MM | 335.28 |
| Std Carton Width In | 10.25 |
| Std Carton Width MM | 260.35 |
| Std Ctn Qty | 250 |
| Std Package Height In | 1.7 |
| Std Package Height MM | 43.18 |
| Std Package Length In | 7.25 |
| Std Package Length MM | 184.15 |
| Std Package Width In | 5.05 |
| Std Package Width MM | 128.27 |
| Sub Brand | NetKey? |
| Termination Style | Punchdown |
| UOM EA PK | PK |
| UPC | 07498399715 |
| Wiring Scheme | T568A/T568B |
