MEAN WELL

B07HHFMVQD

Mean Well ELG-200-C1400A LED Power Supplies, 198.8W71-142V 1400mA for Input 200VAC ~ 305VAC, CC IP65 Io Adjustable w/Pot, Const C Mode LED Driver, Input: 100~305VAC 142~431VDC.

Mean Well ELG-200-C1400A LED Power Supplies, 198.8W71-142V 1400mA for Input 200VAC ~ 305VAC, CC IP65 Io Adjustable w/Pot, Const C Mode LED Driver, Input: 100~305VAC 142~431VDC.zoom

Attributes

Key Value
AC inrush currentCold start, 65 at 230VAC
ApplicationLED
Approval AgencyCB, CCC, CE, cURus, EAC.
ASINB073ZCTX4M
Base Product NumberELG-200
Batteries Included?No
Batteries Required?No
Body dimensions244x71x37.5mm
CategoryPower Supplies - Extern.
ColorWhite
Current - Output (Max)1.4A
DescriptionLED POWER SUPPLIES 198..
Detailed Description1.4A 71 ~ 142V Constant.
Digi-Key Part Number1866-5143-ND
DigiKey ProgrammableNot Verified
Dimension (LxWxH)244x71x37.5
Dimming-
Efficiency92%
Electrical connection300mm wires L N
EMC standardsEN55015, EN61000-3-2 cl.
FeaturesOTP, OVP, SCP
IP ratingIP65
Is Discontinued By Manu.No
Kind of power supplyLED
ManufacturerMEAN WELL, MEAN WELL US.
Manufacturer Product Nu.ELG-200-C1400A
Manufacturer seriesELG C
Manufacturer Standard L.14 Weeks
MaterialMetal
MfrMEAN WELL USA Inc.
Mounting TypeChassis Mount
Number of outputs1
Number of Outputs1
Operating modesconstant current
Operating temperature-40...85?C
Operating Temperature-40?C ~ 85?C
Output current700...1400mA
Output voltage71...142V DC
PackageBox
Packing12pcs / 15.2kg
Part NumberELG-200-C1400A
Power200W
Power (Watts)199 W
Product StatusActive
Protectionanti-overvoltage OVP,
RatingsIP65
SeriesELG-200-C (200W)
Setup, rise, hold up ti.500ms
Size / Dimension8.66" L x 2.80" W x 1.4.
Termination StyleWire Leads
TopologyAC DC Converter
Typeconstant current
Type of power supplyswitched-mode
Voltage - Input (Max)305VAC
Voltage - Input (Min)100VAC
Voltage - Isolation3.75 kV
Voltage - Output71 ~ 142V
Working temperature-40~+80?C (refer to out.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.comELG200C1400A45.01In StockMean Well45.0 @ 1
Component Distributors Inc.ELG-200-C1400A45.01In StockMean Well45.0 @ 1
thumbzoompowersupplymall.comELG-200-C1400A46.661In StockMean Well46.66 @ 1
Electro SonicELG200C1400A47.71In StockMean Well47.7 @ 1
Mouser709-ELG200-C1400A48.01In StockMean Well48.0 @ 1
thumbzoomTMEELG-200-C1400A50.2127MEAN WELL50.2 @ 1
electricautomationnetwork.comELG-200-C1400A60.051In StockMEANWELL60.05 @ 1
thumbzoomDigi-Key945175663.396130MEAN WELL USA Inc.63.396 @ 1
thumbzoomAmazonSCB073ZCTX4M72.961In StockMEAN WELL72.96 @ 1
