mpn:
brand:
manufacturer:
MPN:
Description:
MEAN WELL ELG-240-C1750 | Power supply: switched-mode; LED; 239.75W; 69?137VDC; 1750mA; IP6
Weight:
2.31
Weight:
2.75 LB
Preferred Price:
92.29
Price:
92.29
Min Simple Price:
47.7
Absolute Min Price:
72.73
Min Price:
72.73
Dimensions:
[10.0, 3.0, 2.0]
qty:
28
simpleSku:
DM4NzI:::ELG-240-C1750
sku:
DM4NzI::YS:ELG-240-C1750@y0
condition:
11
seller:
peaktopeakpower.com
amzMan:
mean well
HazMat:
False
DropShip:
True
Attributes
| Key | Value |
|---|---|
| 380 ~ 435V | 250 ~ 290V |
| AC inrush current | Cold start, 75 at 230VAC |
| Additional functions | active PFC |
| Application | LED |
| Approval Agency | CB, CCC, CE, cURus, ENEC |
| ASIN | B073ZC5LYS |
| Base Product Number | ELG-240 |
| Batteries Included? | No |
| Batteries Required? | No |
| Body dimensions | 244x71x37.5mm |
| Category | Power Supplies - External/Internal (Off-Board) |
| Color | White |
| Current - Output (Max) | 1.75A |
| Description | LED DRVR CC AC/DC 69-137V 1.75A |
| Detailed Description | 1.75A 69 ~ 137V Constant Current LED Driver AC DC Converter Topology 1 Output |
| Digi-Key Part Number | 1866-1549-ND |
| Digi-Key Programmable | Not Verified |
| Dimension (LxWxH) | 244x71x37.5 |
| Dimensions | 244*71*37.5 mm (L*W*H) |
| Dimmable | Dimming |
| Dimming | - |
| Efficiency | 93% |
| Electrical connection | 300mm wires L N |
| EMC standards | EN55015, EN61000-3-2 class C,EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, GB17743,GB17625.1 |
| Features | OTP, OVP, SCP |
| Industry Aliases | new |
| Input Voltage | NA |
| IP rating | IP67 |
| Is Discontinued By Manufacturer | No |
| Kind of power supply | LED |
| Manufacturer | MEAN WELL, MEAN WELL USA Inc. |
| Manufacturer Product Number | ELG-240-C1750 |
| Manufacturer series | ELG C |
| Manufacturer Standard Lead Time | 18 Weeks |
| Material | Metal |
| Mfr | MEAN WELL USA Inc. |
| Model Type | C-Type |
| Mounting Type | Chassis Mount |
| Number of outputs | 1 |
| Number of Outputs | 1 |
| Operating modes | constant current |
| Operating temperature | -40...85?C |
| Operating Temperature | -40?C ~ 85?C |
| Output current | 1.75A |
| Output voltage | 69...137V DC |
| Output Voltage | NA |
| Package | Box |
| Packing | 12pcs / 15.2kg |
| Part Number | ELG-240-C1750 |
| Power | 239.75W |
| Power (Watts) | 240 W |
| Product Status | Active |
| Protection | anti-overvoltage OVP, |
| Ratings | IP67 |
| Series | ELG-240-C (240W) |
| Setup, rise, hold up time | 500ms |
| Size / Dimension | 8.66" L x 2.80" W x 1.48" H (220.0mm x 71.0mm x 37.5mm) |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | constant current |
| Type of power supply | switched-mode |
| Voltage - Input (Max) | 305VAC |
| Voltage - Input (Min) | 100VAC |
| Voltage - Isolation | 3.75 kV |
| Voltage - Output | 69 ~ 137V |
| Wattage | 104 |
| Working temperature | -40~+80?C (refer to output derating curve) |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | peaktopeakpower.com | ELG-240-C1750 | 47.7 | 47.7 | 1 | In Stock | Mean Well | 47.7 @ Qty: 1+ | ||
 | powersupplymall.com | ELG-240-C1750 | 47.85 | 47.85 | 1 | In Stock | Mean Well | 47.85 @ Qty: 1+ | ||
| Component Distributors Inc. | ELG-240-C1750 | 48.6 | 48.6 | 1 | In Stock | Mean Well | 48.6 @ Qty: 1+ | |||
 | AmazonSC | B073ZC5LYS | 60.37 | 60.37 | 1 | In Stock | MEAN WELL | 60.37 @ Qty: 1+ | ||
| electricautomationnetwork.com | ELG-240-C1750 | 63.71 | 63.71 | 1 | In Stock | MEANWELL | 63.71 @ Qty: 1+ | |||
 | Digi-Key | 7703003 | 65.976 | 65.976 | 1 | In Stock | MEAN WELL USA Inc. | 65.976 @ Qty: 1+ | ||
 | TME | ELG-240-C1750 | 66.5 | 66.5 | 1 | 28 | MEAN WELL | 66.5 @ Qty: 1+ |
