MEAN WELL

B07LFKTBBL

Mean Well LPV-60-24 Single Output LED Power Supply CV 60W 24V 2.5A, IP67, Cable Output, Low Cost, Free air Convection, Input: 90~264VAC

Mean Well LPV-60-24 Single Output LED Power Supply CV 60W 24V 2.5A, IP67, Cable Output, Low Cost, Free air Convection, Input: 90~264VACzoom

Attributes

Key Value
-30 CStart Temp. (Min)
1Case Quantity
1.2A/115VAC 1A/230V.Input Current
162.5 mmLength (in)
2 YearsWarranty
24VDCSecondary Voltage
32 mmHeight (in)
42.5 mmWidth (in)
70 CStart Temp. (Max)
86%Efficiency (typical)
90~264VAC 50/60HzFirst Voltage
AC Current (Typ.)1.2A / 115VAC 1A / 23.
Approval AgencyCB, CE, cURus
ASINB072JDF9GQ
Base Product NumberLPV-60
BrandMean Well
Case Size10
CategoryPower Supplies - Extern.
ConfigurationEncapsulated
Current - Output (Max)2.5A
DescriptionLED DRIVER CV AC/DC 24V.
Detailed Description2.5A 24V Constant Volta.
Digi-Key Part Number1866-3306-ND
DigiKey ProgrammableNot Verified
Dimension162.5 x 42.5 x 32mm (Lx.
Dimensions6.40(L) x 1.67"(W) x 1..
DimmingNon Dimming, -
Driver TypeConstant-Voltage
Efficiency86%
Efficiency (Typ.)75%
EMC EmissionCompliance to EN55022 (.
EMC ImmunityCompliance to EN61000-4.
FeaturesOCP, OVP, SCP
Fixture TypeLED
Hold up Time50ms / 230 VAC 16ms/.
Industry Aliasesnew
Input Voltage90 ~ 264 VAC Universal,.
Input Voltage Range100-264 VAC
Inrush Current (Typ.)COLD START 60A (twidth=.
Isolation ResistanceI/P - O/P : 100M Ohms /.
Item model numberLPV-60-24
Lead Free Status / RoHS.RoHS Compliant
Leakage Current<0.25mA / 240VAC
LEDBulb Type
LED Driver / LP SeriesFamily
Load Regulation?6.0%
Location RatingDry/Damp
LPV-60-24Stock Code
ManufacturerMEAN WELL USA Inc.
Manufacturer Part No.LPV-60-24
Manufacturer Part NumberLPV-60-24
Manufacturer Product Nu.LPV-60-24
Manufacturer Standard L.17 Weeks, 14 Weeks
Max Output Current2500mA
Max Output Power60W
Max Output Voltage24V
Max. 60 WattWattage (w)
MeanwellBrand
MfrMEAN WELL USA Inc.
Mounting TypePanel Mount, Chassis Mo.
MTBF732Khrs min. MIL-HDBK-2.
Number of Outputs1
Operating Temperature-30?C ~ 70?C, -30
OperationSwitching
Our Part No.BSFM-LPV-60-24
Output Current2.5 A
Output Power60 W
Output Rated Current2.5A
Output Voltage24V, 24 VDC
Over Voltage5.75~6.75V
Overload110 ~ 150% rated output.
PackageBox
Packing0.4Kg; 32pcs / 13.8Kg /.
Plastic CaseHousing
Power (Watts)60 W, 60W
Primary TypeAC-DC
Product StatusActive
RatingsIP67
RU, cRU ListedUL Listed
Safety StandardsUL879(except for LPV-60.
SeriesLPV-60 Series, LPV-60 (.
Setup, Rise Time500ms, 20ms / 230VAC --.
Size / Dimension6.40" L x 1.67" W x 1.2.
Special Features2 Year Warranty ; 100% .
Standard Package32
Storage Temp., Humidity-40 ~ +80?C, 10 ~ 95% RH
Temp. Coefficient?0.03%/?C (0 ~ 50?C)
Termination StyleWire Leads
TopologyAC DC Converter
TypeLED Driver, Constant Vo.
UL ClassClass 2
Vibration10 ~ 500Hz, 2G 10min. /.
Voltage120 to 277
Voltage - Input (Max)264VAC
Voltage - Input (Min)90VAC
Voltage - Isolation3 kV, 3kV
Voltage - Output24V
Voltage Range90~264VAC 127~370VDC
WarrantyManufacturer's 5 Year
Wattage60
Withstand VoltageI/P - O/P : 3KVAC
Working Humidity20 ~ 90% RH non-condens.
Working Temp.-30 ~ +70?C (Refer to ".

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
iodPartsLPV-60-2412.8320960MEAN WELL12.83 @ 20
Onlinecomponents.comLPV-60-2414.01806MEAN WELL14.0 @ 1
Sager ElectronicsLPV-60-2414.815284Mean Well14.8 @ 1
thumbzoompowersupplymall.comLPV-60-2416.4911437Mean Well16.49 @ 1
electricautomationnetwork.comLPV-60-2417.731In StockMEANWELL17.73 @ 1
thumbzoomTMELPV-60-2418.01In StockMEAN WELL18.0 @ 1
thumbzoomNewark06W074618.841210MEAN WELL18.84 @ 1
thumbzoompeaktopeakpower.comLPV-60-2418.91In StockMean Well18.9 @ 1
Future Electronics405739419.51214918MEAN WELL19.512 @ 1
us.rs-online.com7006968019.6618698MEAN WELL19.66 @ 1
AmazonTPB004I6BLQ421.071In StockMEAN WELL21.07 @ 1
thumbzoomLighting SupplyLPV-60-2421.2311Mean Well21.23 @ 1
thumbzoomDigi-Key770499821.63611589MEAN WELL USA Inc.21.636 @ 1
thumbzoomballastshop.comBSFM-LPV-60-2425.951In StockMean Well25.95 @ 1
thumbzoomAmazonSCB072JDF9GQ30.21In StockMEAN WELL0.9187530.2 @ 1
RadwellLPV-60-2433.351In StockMEAN WELL33.35 @ 1
thumbzoomace4parts.comLPV-60-2435.01In StockMean Well USA, Inc.35.0 @ 1
thumbzoombulbspro.comLPV-60-2437.51In StockMeanwell37.5 @ 1
RS Delivers660-030051.8641657Mean Well51.864 @ 1
