Attributes
| Key ^ | Value |
|---|---|
| Automotive Standard | AEC-Q100 |
| Brand | Microchip Technology |
| Dimensions | Dimensions |
| Height | 0.95mm |
| Length, Width | 4mm |
| Maximum Data Rate | 20kBd |
| Maximum Operating Supply Voltage | 27 V |
| Maximum Operating Temperature | +125 ?C |
| Maximum Supply Current | 1 mA |
| Minimum Operating Supply Voltage | 6 V |
| Minimum Operating Temperature | -40 ?C |
| Mounting Type | Surface Mount |
| Number of Transceivers | Number of Transceivers |
| Package Type | DFN |
| Pin Count | 8 |
| Standard Supported | LIN 1.3, LIN 2.0, LIN 2.1, SAE J2602 |
| Stock | Stock |
