- mpn240-SC-02-O(JAA)-5P
- brandname: MIDWEST INSTRUMENT
- manufacturername: MIDWEST INSTRUMENT
Mid-West 240-SC-02-O(JAA)-5P Differential Pressure Gauge with 316 Stainless Steel Body and 316 Stainless Steel/Ceramic Internals, 1 Control Switch in NEMA 7 Class1-Div.1 Explosion Proof Enclosure, Diaphragm Type, 3/2/3% Full Scale Accuracy, 4-1/2" Dial, 1/4" FNPT End Connection, 0-5 psid Range, 1500 psig SWP
- Brand: Mid-West Instrument
- PartNumber: 240-SC-02-O(JAA)-5P
- Model: 240-SC-02-O(JAA)
- Size: 0-5 psid
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Mid-West Instrument
- Label: Mid-West Instrument
Attributes
| Key | Value |
|---|
| (Hidden) max pressure d. | 1,500 psig x For High O. |
| (Hidden) Series x Accur. | +/-3-2-3% x 240 |
| Accuracy | ?3-2-3%, +/-3-2-3% |
| Accuracy Grade | ASME B40.1 Grade B |
| Adjustable Set Points | Yes |
| Ambient Operating Tempe. | -40? to 185?F (-40? to . |
| Application | Filtration Monitoring, . |
| Application - Max Press. | For High Operating Pres. |
| Basic Gauge Case Materi. | Plastic |
| Basic Gauge Wetted Parts | Stainless Steel / Buna-N |
| Bezel Gasket Material | Buna-N |
| Blowout Safety Back | No |
| Body Material | 316 Stainless Steel |
| Brand | MIDWEST INSTRUMENT |
| Brand and Series | MIDWEST INSTRUMENT 240 |
| Case Diameter | 6-3/16 in, 6 3/16 in |
| Case Material | Plastic |
| Case Shape | Round |
| Catalog Page | N/A |
| Connection Location | In-Line |
| Contact Rating | 0.25A, 125V AC/V DC |
| Country of Origin | USA |
| Country of Origin (subj. | United States |
| Dial Color | White |
| Dial Material | Engineered Plastic |
| Diaphragm Material | Buna-N |
| Differential Gauge Conn. | 1/4 in |
| Differential Gauge Conn. | FNPT |
| Differential Pressure G. | Differential Pressure G. |
| Differential Pressure R. | 0 to 5 psi |
| Differential Pressure R. | psi |
| Differential Pressure R. | 0 to 5 |
| Gauge Accuracy | +/-3-2-3% |
| Gauge Case Material | Plastic |
| Gauge Connection Locati. | Inline |
| Gauge Nominal Dial Size | 4 1/2 in |
| Gauge Operating Temp. R. | -40 Degrees to 185 Deg. |
| Gauge Primary Range Sma. | 0.5 |
| Hazardous Location Rati. | Class I, Div I, Groups . |
| Housing Material | 316 Stainless Steel |
| Includes | Installation and Operat. |
| Includes Calibration Ce. | No |
| Includes Mounting Hardw. | No |
| Includes Vent Plug | No |
| IP/NEMA Rating | NEMA 4X |
| Item | Differential Pressure G. |
| Item? | 22A550 |
| Lens Material | Acrylic |
| Manufacturer Part Number | 240-SC-02-O(JAA)-5P |
| Manufacturer Warranty L. | 5 yr |
| Manufacturers Warranty . | 5 yr |
| Max Pressure Application | For Medium Operating Pr. |
| Maximum Working Static . | 1,500 psig |
| Mfr. Model? | 240-SC-02-O(JAA)-5P |
| Movement Material | Ceramic |
| Nominal Dial Size | 4-1/2 in, 4 1/2 in |
| Non-Sparking | No |
| Number of Switches | 1 |
| O-Ring Material | Buna-N |
| Panel-Mountable | No |
| Piston Material | Stainless Steel |
| Pressure Gauge Type | Differential Pressure G. |
| Pressure Range | 0 to 5 psid |
| Process Connection | 1/4 in NPT Female |
| Process Connection Gend. | Female |
| Process Connection Loca. | End |
| Process Connection Size | 1/4 in |
| Process Connection Type | NPT |
| Rated Total Pressure | 1500 psi |
| Relay Type | SPDT |
| Removable Bezel | No |
| Repeatability | +/-1% |
| Scale Type | Pressure |
| Seal Material | Buna-N |
| Sensor Material | Buna-N |
| Sensor Type | Diaphragm |
| Series | Series 240, 240 |
| Standards | ATEX; CE; CSA; EU RoHS2. |
| Switch Contact Type | SPDT |
| Switch Electrical Requi. | 0.25A @ 125V AC/DC; 3W |
| UNSPSC | 41112403 |
| Wetted Parts Material | Stainless Steel/Buna-N |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Grainger | 22A550 | 995.39 | 1 | In Stock | | MIDWEST INSTRUMENT | | 995.39 @ 1 |
 | Zoro | G5659543 | 1052.49 | 1 | In Stock | 26 | Midwest Instrument | 8.0 | 1052.49 @ 1 |
 | Raptor Supplies | AB6QFX | 1390.251564 | 1 | In Stock | | MIDWEST INSTRUMENTS | | 1390.251564 @ 1 |
