| Amperage Range | 3 to 400 A |
| Application | Aerospace Ship Repair, Heavy Fabrication, Pipe and Tube Fabrication, Precision Fabrication |
| brand-mfr model | MILLER ELECTRIC - 907716001 |
| Color | Blue/Black |
| Country of Origin (subject to change) | United States |
| Features | Blue Lightning(TM) HF, Cooler Power Supply, Cooler-On-Demand(TM), Fan-On-Demand(TM), Hot Start(TM), Independent Amplitude/Amperage, Meter Calibration, Operator Friendly Interface, Pro-Set(TM), Program Memory |
| For Material Type | Specialty Metals, Stainless Steel, Steel |
| For Maximum Material Thickness | 5/8 in (Mild Steel) |
| For Minimum Material Thickness | 0.012 in (Mild Steel) |
| Includes | Coolmate(TM) 3.5, Maxstar(R) 400, Runner Cart |
| Input (Amps) | 33/30/17/15/12/12/11.6 |
| Input Frequency | 50/60 Hz |
| Input Voltage | 208 to 575V AC |
| Input Voltage (Nominal) | 208V, 240V, 400V, 480V, 575V |
| Item | TIG Welder |
| Kit Includes | Running Gear, Water Cooler |
| Max. Amperage Range (TIG) | Greater than 300 A |
| Max. Input Current | 33 A @ 208V (Three-Phase), 48 A @ 208V (Single-Phase) |
| Mild Steel - Material Thickness | 0.012 in to 5/8 in |
| Model | 907716001 |
| Open Circuit Voltage | 75V DC |
| Overall Depth | 43 3/4 in |
| Overall Height | 24 3/4 in |
| Overall Width | 23 1/8 in |
| Plug Type | Bare Leads |
| Polarity | DC |
| Power Cord Length | 8 ft |
| Power Source Weight | 251 lb |
| Process | Stick Welding (SMAW), TIG Welding (GTAW) |
| Process (Merch) | GTAW, SMAW, CAC-A |
| Promotion Restriction | Not eligible for promotion |
| Rated Output | 300A @ 32V, 60% |
| Rated Output at Duty Cycle (TIG) | 300 A @ 60% |
| Remote Control | No |
| Series | Maxstar(R) |
| Stick Welding Maximum Output Current | 400 A |
| Stick Welding Minimum Output Current | 3 A |
| Stick Welding Output @ Duty Cycle | 300 A @ 32 V, 60% |
| TIG Welding Maximum Output Current | 400 A |
| TIG Welding Minimum Output Current | 3 A |
| TIG Welding Output @ Duty Cycle | 300 A @ 32 V, 60% |
| Weight | 308 lb |
| Welded Material | Mild Steel, Stainless Steel |
| Welder Duty Cycle | 80 % |
| Welder Industrial Class | Heavy |
| Welder Input Hz | 50/60 |
| Welder Input Phase | 1 or 3 |
| Welder Kit Type | Base Model w/Water Cooler |
| Welder Max. Output Amps | 400 |
| Welder Min. Output Amps | 3 |
| Welder Type (Merch) | Base Model w/Water Cooler |
| Welding Mode | CC |
| Welding Processes | Pulsed TIG, Stick, TIG |
