- mpn0395300016
- brandname: Molex
- manufacturername: Molex
39530-0016, Conn Eurostyle Block F 16 POS 5.08mm Screw RA Cable Mount 15A/Contact (5 Items)
- Brand: Molex / Waldom
- PartNumber: 39530-0016
- Model: 39530-0016
- Manufacturer: Molex / Waldom
- Label: Molex / Waldom
Attributes
| Key | Value |
|---|
| Base Product Number | 039530 |
| Category | Connectors, Interconnec. |
| Circuits (Loaded) | 16 |
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Contact Tail Length | - |
| Current - IEC | - |
| Current - Maximum per C. | 18.0A |
| Current - UL | 15 A |
| Current Rating | 18 A |
| Description | TERM BLOCK PLUG 16POS S. |
| Detailed Description | 16 Position Terminal Bl. |
| Digi-Key Part Number | 0395300016-ND |
| Entry Angle | Vertical |
| Family Name | ESE |
| Features | Retention Latches (Non-. |
| Header Orientation | - |
| Housing Material | Polyamide (PA), Nylon |
| Ingress Protection | - |
| Insulation Height | 0.591" (15.00mm) |
| Lock to Mating Part | Yes |
| Manufacturer | Molex |
| Manufacturer Product Nu. | 0395300016 |
| Manufacturer Standard L. | 12 Weeks |
| Material Flammability R. | - |
| Mfr | Molex |
| Mounting Type | Free Hanging (In-Line) |
| Number of Circuits | 16 |
| Number of Levels | 1 |
| Number of Positions | 16 |
| Number of Rows | 1 |
| Operating Temperature | -40?C ~ 115?C |
| Orientation | Horizontal |
| Package | Bulk |
| Panel Mount | No |
| Pitch | 0.200" (5.08mm) |
| Pitch - Mating Interface | 5.08mm |
| Pitch - Termination Int. | 5.08mm |
| Plug Wire Entry | 180? |
| Polarized to Mating Part | Yes |
| Positions Per Level | 16 |
| Product Status | Active |
| Screw Size | M3 |
| Series | Eurostyle ESE 39530, 39. |
| Stackable | No |
| Temperature Range - Ope. | -40? to +105?C |
| Termination Style | Screw - Rising Cage Cla. |
| Torque - Screw | 0.56 Nm (5.0 Lb-In) |
| Type | Plug, Female Sockets |
| UL | E48521 |
| Voltage - Maximum | 300V |
| Voltage - UL | 300 V |
| Wire Gauge or Range - A. | 12-26 AWG |
| Wire Gauge or Range - m. | - |
| Wire Size AWG | 12, 14, 16, 18, 20, 22,. |
| Wire Size mm? | 0.13-3.31 |
| Wire Strip Length | 5mm |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Waldom | MOLEX 39530-0016 | 4.9 | 15 | 1999 | | MOLEX | | 4.9 @ 15 |
| Heilind Electronics | 39530-0016 | 5.4153 | 30 | In Stock | | MOLEX | | 5.4153 @ 30 |
| Onlinecomponents.com | 39530-0016 | 5.85 | 1 | 1920 | | MOLEX / WALDOM | | 5.85 @ 1 |
 | jensentools.com | 10188828 | 6.53 | 1 | 1999 | | Molex | | 6.53 @ 1 |
 | Digi-Key | 2738340 | 7.005888 | 648 | In Stock | | Molex | | 7.005888 @ 648 |
| us.rs-online.com | 71457290 | 8.82 | 1 | In Stock | | Molex Incorporated | | 8.82 @ 1 |
| Newark | 20M3716 | 10.56 | 1 | 1959 | | MOLEX | | 10.56 @ 1 |
| AmazonTP | B07QG4GS27 | 61.58 | 1 | In Stock | 1 | Molex / Waldom | | 61.58 @ 1 |
 | Zoro | G605798224 | 92.85 | 1 | In Stock | | Molex | | 92.85 @ 1 |
