Molex 39530-0022

B00O0IG746

Molex 5.08Mm Euro Plug Ra Blk 22Ckt - 39530-0022

Molex 5.08Mm Euro Plug Ra Blk 22Ckt - 39530-0022zoom

Attributes

Key Value
Base Product Number039530
CategoryConnectors, Interconnec.
Circuits (Loaded)22
ColorBlack
Contact MaterialCopper Alloy
Contact Mating FinishTin
Contact Tail Length-
Current - IEC-
Current - Maximum per C.18.0A
Current - UL15 A
DescriptionTERM BLOCK PLUG 22POS S.
Detailed Description22 Position Terminal Bl.
Digi-Key Part Number0395300022-ND
Entry AngleVertical
FeaturesRetention Latches (Non-.
Header Orientation-
Housing MaterialPolyamide (PA), Nylon
Ingress Protection-
Insulation Height0.591" (15.00mm)
Lock to Mating PartYes
ManufacturerMolex
Manufacturer Product Nu.0395300022
Manufacturer Standard L.12 Weeks
Material Flammability R.-
MfrMolex
Mounting TypeFree Hanging (In-Line)
Number of Levels1
Number of Positions22
Number of Rows1
Operating Temperature-40?C ~ 115?C
OrientationHorizontal
PackageBulk
Panel MountNo
Pitch0.200" (5.08mm)
Pitch - Mating Interface5.08mm
Pitch - Termination Int.5.08mm
Plug Wire Entry180?
Polarized to Mating PartYes
Positions Per Level22
Product StatusActive
Screw SizeM3
SeriesEurostyle ESE 39530
StackableNo
Temperature Range - Ope.-40? to +105?C
Termination StyleScrew - Rising Cage Cla.
Torque - Screw0.56 Nm (5.0 Lb-In)
TypePlug, Female Sockets
ULE48521
Voltage - Maximum300V
Voltage - UL300 V
Wire Gauge or Range - A.12-26 AWG
Wire Gauge or Range - m.-
Wire Size AWG12, 14, 16, 18, 20, 22,.
Wire Size mm?0.13-3.31
Wire Strip Length5mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomMOLEX 39530-00226.7210111MOLEX6.72 @ 10
Verical39530-00227.66552Molex7.66 @ 5
Onlinecomponents.com39530-00228.031190MOLEX / WALDOM8.03 @ 5
thumbzoomjensentools.com101888298.961111Molex8.96 @ 5
thumbzoomDigi-Key27383469.2533325405Molex9.253332 @ 540
Newark03N644310.471111MOLEX10.47 @ 5
Mouser538-39530-002212.441161Molex12.44 @ 5
thumbzoomRadwell39530-002216.01205MOLEX16.0 @ 120
thumbzoomZoroG20579875484.915Molex84.9 @ 5
