Molex / Waldom 39536-0007

B07QPBMLDG

39536-0007, Conn Shrouded Header HDR 7 POS 5.08mm Solder RA Thru-Hole Eurostyle (25 Items)

39536-0007, Conn Shrouded Header HDR 7 POS 5.08mm Solder RA Thru-Hole Eurostyle (25 Items)zoom

Attributes

Key Value
Base Product Number039536
CategoryConnectors, Interconnec.
Circuits (Loaded)7
ColorBlack
Contact MaterialBrass
Contact Mating FinishTin
Contact Tail Length-
Current - IEC-
Current - Maximum per C.15.0A
Current - UL18 A
DescriptionTERM BLOCK HDR 7POS 90D.
Detailed Description7 Position Terminal Blo.
Digi-Key Part Number0395360007-ND
FeaturesMating Flange
Header Orientation90?, Right Angle
Housing MaterialPolyamide (PA66), Nylon.
Ingress Protection-
Insulation Height-
Lock to Mating PartYes
ManufacturerMolex
Manufacturer Product Nu.0395360007
Manufacturer Standard L.13 Weeks
Material Flammability R.UL94 V-0
MfrMolex
Mounting TypeThrough Hole
Number of Levels1
Number of Positions7
Number of Rows1
Operating Temperature-40?C ~ 105?C
OrientationHorizontal
PackageBulk
Package Quantity1
Panel MountNo
PC Tail Length5.08mm
PCB Thickness - Recomme.3.20mm
Pitch0.200" (5.08mm)
Pitch - Mating Interface5.08mm
Pitch - Termination Int.5.08mm
Plug Wire Entry-
Polarized to Mating PartYes
Positions Per Level7
Product StatusActive
Screw Size-
SeriesEurostyle ESE 39536
ShroudedClosed Ends
StackableNo
Temperature Range - Ope.-40? to +140?C
Termination StyleSolder
Torque - Screw-
TypeHeader, Male Pins, Shro.
ULE48521
Voltage - Maximum300V
Voltage - UL300 V
Wire Gauge or Range - A.-
Wire Gauge or Range - m.-
Wire Strip Length-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.com39536-00071.471270MOLEX / WALDOM1.47 @ 1
thumbzoomDigi-Key27401511.593564180062Molex1.593564 @ 1800
WaldomMOLEX 39536-00071.9330388MOLEX1.93 @ 30
thumbzoomjensentools.com101889282.04149Molex2.04 @ 1
Newark45P92772.391388MOLEX2.39 @ 1
thumbzoomZoroG10591904483.65162Molex83.65 @ 1
