| Circuits (Loaded), Number of Rows, Package Quantity | 1 |
| Color - Resin | Grey |
| Current - Maximum per Contact | 230.0A |
| Entry Angle | Horizontal |
| Lock to Mating Part | None |
| Material - Metal | Aluminum |
| Material - Plating Mating, Material - Plating Termination | Tin |
| Material - Resin | Polyamide |
| Orientation | Vertical |
| Panel Mount | Screws |
| Stackable | No |
| Temperature Range - Operating | -40? to +105?C |
| Termination Interface: Style | Screw |
| UL | E48521 |
| Voltage - Maximum | 600V |
| Wire Size AWG | 2(2-6), 4/0-4, 6+6+6 |
| Wire Size mm? | 13.30+13.30+13.30, 2(13.30-33.60), 21.00-107.00 |
