Molex 0901200770

B07QYCSV9D

0901200770 Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole C-Grid III Tray, (25 Items)

0901200770 Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole C-Grid III Tray, (25 Items)zoom

Attributes

Key Value
ApplicationsAutomotive, General Pur.
Base Product Number090120
CategoryConnectors, Interconnec.
Connector TypeHeader, Breakaway
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thicknes.15.0?in (0.38?m)
Contact Finish Thicknes.118.1?in (3.00?m)
Contact Length - Mating0.266" (6.75mm)
Contact Length - Post0.114" (2.90mm)
Contact MaterialBrass
Contact ShapeSquare
Contact TypeMale Pin
Current Rating (Amps)-
DescriptionCONN HEADER VERT 10POS .
Detailed DescriptionConnector Header Throug.
Digi-Key Part NumberWM8092-ND
Fastening TypePush-Pull
Features-
Ingress Protection-
Insulation ColorBlack
Insulation Height0.098" (2.50mm)
Insulation MaterialPolyester, Glass Filled
ManufacturerMolex
Manufacturer Product Nu.0901200770
Manufacturer Standard L.13 Weeks
Mated Stacking Heights-
Material Flammability R.UL94 V-0
MfrMolex
Mounting TypeThrough Hole
Number of Positions10
Number of Positions Loa.All
Number of Rows1
Operating Temperature-
Overall Contact Length0.478" (12.15mm)
PackageBulk
Pitch - Mating0.100" (2.54mm)
Product StatusActive
Row Spacing - Mating-
SeriesC-Grid III 90120
ShroudingUnshrouded
StyleBoard to Board or Cable
TerminationSolder
Voltage Rating-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomNewark26M78740.4191336MOLEX0.419 @ 10
thumbzoomDigi-Key7608071.09735180010Molex1.09735 @ 1800
thumbzoomTMEMX-90120-07701.14175MOLEX1.14 @ 10
HotendaH13028361.446110Molex1.446 @ 10
Mouser538-90120-07701.512517Molex1.5 @ 10
Arrow90120-07701.81811081Molex1.818 @ 10
RS Delivers360-62852.1181225Molex2.118 @ 10
thumbzoomZoroG50589109487.0110Molex87.0 @ 10
