Molex 44472-1453

B00LS9T02G

Molex Header Connector,PCB Mount,recept,14 Contacts,pin,0.165 Pitch,pc Tail Terminal,Polarized Lck - 44472-1453

Molex Header Connector,PCB Mount,recept,14 Contacts,pin,0.165 Pitch,pc Tail Terminal,Polarized Lck - 44472-1453zoom

Attributes

Key Value
ApplicationsAutomotive, General Pur.
Base Product Number044472
CategoryConnectors, Interconnec.
Connector TypeHeader
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Finish Thicknes.100.0?in (2.54?m)
Contact Finish Thicknes.100.0?in (2.54?m)
Contact Length - Mating-
Contact Length - Post0.138" (3.50mm)
Contact MaterialCopper Alloy
Contact ShapeSquare
Contact TypeMale Pin
Current Rating (Amps)-
DescriptionCONN HEADER VERT 14POS .
Detailed DescriptionConnector Header Throug.
Digi-Key Part Number0444721453-ND
Fastening TypeLocking Ramp
FeaturesBoard Lock
Ingress Protection-
Insulation ColorNatural
Insulation Height0.504" (12.80mm)
Insulation MaterialPolyamide (PA66), Nylon.
ManufacturerMolex
Manufacturer Product Nu.0444721453
Manufacturer Standard L.28 Weeks
Mated Stacking Heights-
Material Flammability R.UL94 V-0
MfrMolex
Mounting TypeThrough Hole
Number of Positions14
Number of Positions Loa.All
Number of Rows2
Operating Temperature-
Overall Contact Length-
PackageTray
Package Quantity1
Pitch - Mating0.165" (4.20mm)
Product StatusActive
Row Spacing - Mating0.165" (4.20mm)
SeriesMini-Fit HCS 44472
ShroudingShrouded - 4 Wall
StyleBoard to Cable/Wire
TerminationSolder
Voltage Rating-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.com44472-14532.441390MOLEX / WALDOM2.44 @ 1
Newark92M26763.77126MOLEX3.77 @ 1
thumbzoomDigi-Key42474744.3468154026Molex4.34681 @ 540
thumbzoomRadwell44472-14537.054026MOLEX7.0 @ 540
thumbzoomZoroG80591059485.5822In StockMolex85.58 @ 22
