Attributes
| Key ^ | Value |
|---|---|
| Applications | Automotive, General Purpose, Lighting, Medical, Telecommunications |
| Base Product Number | 001097 |
| Category | Connectors, Interconnects |
| Connector Type | Header, Breakaway |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 15.0?in (0.38?m) |
| Contact Finish Thickness - Post | 74.8?in (1.90?m) |
| Contact Length - Mating | 0.320" (8.13mm) |
| Contact Length - Post | 0.110" (2.79mm) |
| Contact Material | Copper Alloy |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Current Rating (Amps), Features, Ingress Protection, Mated Stacking Heights, Operating Temperature, Voltage Rating | - |
| Description | CONN HEADER VERT 4POS 2.54MM |
| Detailed Description | Connector Header Through Hole 4 position 0.100" (2.54mm) |
| Digi-Key Part Number | WM22468-ND |
| Fastening Type | Push-Pull |
| Insulation Color | Black |
| Insulation Height | 0.090" (2.29mm) |
| Insulation Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Manufacturer Product Number | 0010977046 |
| Manufacturer Standard Lead Time | 8 Weeks |
| Manufacturer, Mfr | Molex |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 4 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Overall Contact Length | 0.520" (13.21mm) |
| Package | Bulk |
| Pitch - Mating, Row Spacing - Mating | 0.100" (2.54mm) |
| Product Status | Active |
| Series | C-Grid 70280 |
| Shrouding | Unshrouded |
| Style | Board to Board or Cable |
| Termination | Solder |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Onlinecomponents.com | 10-97-7046 | 0.284 | 42.7136 | 1 | 4710 | MOLEX / WALDOM | 0.284 @ Qty: 250+ | |||
| Waldom | MOLEX 10-97-7046 | 0.3 | 69.0 | 200 | 6000 | MOLEX | 0.3 @ Qty: 250+ | |||
 | jensentools.com | 10151195 | 0.4 | 60.16 | 1 | 250 | Molex | 0.4 @ Qty: 250+ | ||
 | Digi-Key | 3068119 | 0.4026 | 60.55104 | 1 | 7420 | Molex | 0.4026 @ Qty: 250+ | ||
| Heilind Electronics | 10-97-7046 | 0.41562 | 114.71112 | 315 | 315 | MOLEX | 0.41562 @ Qty: 315+ | |||
| Newark | 90M4206 | 0.43 | 64.672 | 1 | 5340 | MOLEX | 0.43 @ Qty: 250+ | |||
 | Zoro | G2759188 | 122.0 | 18348.8 | 1 | 250 | Molex | 122.0 @ Qty: 250+ |
